7” H-4 Head-
lamp Assembly
• Without chrome
outer rim. Headlamp
is attached to a black
housing.
VT No. 33-3041
H9 High Beam Headlamp
Replacement Bulb
• Fits 2014-up FLHX, FLHXS, FLHR.
OEM # 67717-01.
VT No. 33-1447
33-1447
SMD LED H4 Headlight “Bulbs”
These LED projector bulbs feature state of the art SMD technology and
have a heavy duty construction with , unlike conventional bulbs, a high
resistance to torsional frame vibrations. The high powered patterned
SMD type LEDs provide maximum illumination. They come complete
with socket adapters to allow fitment with any headlight with H4, HS1,
BA20D, T19, P43T or P45 base. High Beam is 1,500 Lumen at only
18 Watt low beam is 1,000 Lumen at only 12 watt, which is better as a
common H4 bulb. Does not require the installation of separate ballast as
these bulbs feature a built-in rotary cooling fan.
LED H4 Bulbs.
VT No.
Color
Connection Type
33-1736
White
H-4 Plug
33-1737
White
Bullet Connectors
33-1738
Yellow
H-4 Plug
33-1739
Yellow
Bullet Connectors
33-1782
White
H-4 Plug
33-1737
12 V
33-1738
110
WWW.VTWINMFG.COM
TOURING
7” Lamp Units
7” Faceted H-4 Lamp Unit
• Features 60/55 bulb with parking lamp.
VT No. 33-0206
33-1557
33-0201
33-0850
Round Sealed Beams are replacement type.
VT No.
Volt
Watt
Brand
33-2009* 12 Volt
60/55
Wagner
33-3072
12 Volt
60/55
Beck
33-1032
12 Volt
60/55
Cycle Beam
*Note: Halogen Type Sealed Beam
Diamond Cut
Lamp Unit
• Features H-4 bulb
and white LED ring.
VT No. 33-0948
7” Halogen Lamp Units
• Feature early styling and H-4, 55-60 watt replaceable bulb
included. Both fit stock or custom headlamp shells. Shell is
not included.
VT No.
Type
Bulb
33-0850
Blue Dot
33-2170
33-0201
Clear Flat
33-2170
33-1557
Flat
33-2170
33-4080
Amber Lens
33-4081
Smoked Lens
33-0110
H-4 Bulb
Candlepower
33-4080
33-4081
33-3072
33-0110
• With 3 pin socket for replacement of H-4 units. Features 360°
beam angle. Low draw won’t drain the battery, remains bright
regardless of battery condition!
**Note: Due to the brightness
of the bulb, the headlight trim angle may need to be adjusted
to avoid distraction of other drivers. Does not work on new
Indians. The overall length is 3³₄” with an extended outer body
length of 1³₄”.
VT No.
Watt
Lumen
33-1782
30
3000
33-1717
25W
2500
White LED 12V Bulb
33-1782
33-1717
33-1032
