255
BIG TWIN
Wyatt Gatling Polished Spoke Rotor.
Number of spokes as noted.
20 Spoke 18 Spoke Type Year
23-0149 23-0679 Front 1984-99
—
23-0678
Rear 1979-99
23-0151 23-1517 Front 2000-up
—
23-1518 Rear 2000-up
—
23-0895 Rear 1979-93
Dura 2000-up Stainless Rotors with vented swirl slots.
VT No. OEM
Type/Side Model
Finish
Year
23-0694 44156-00 Front, Left FXD, FXST Polished 2000-14
23-3774 44136-00 Front, Right FXD, FXST Polished 2000-14
23-0534 44156-00 Front, Left FXD, FXST Steel
2000-14
23-0598 41797-00 Rear
FXD, FXST Polished 2000-up
23-0535
Front, Left FXD, FXST Polished 2000-14
23-0357 41797-00 Rear
FXD, FXST Polished 2000-up
Order Bolts Separately.
X Polished Stainless Rotors.
VT No. Year
Type
23-1520 1984-99 Rear
23-1521 2000-14 Front
23-1522 2000-up Rear
23-1532 2015-up
Front
23-1537 2008-up FLT Front
23-0535
Dura Polished Stainless Brake Discs.
VT No. Year
Type
Bolts
Wheel
23-1512 1984-99 Front 8791-10 Wire
8793-5 Cast
23-1513 1984-99 Rear
9807-10 Wire
23-1514 2000-14 Front 8794-10 Wire
8793-5 Cast
23-1515 2000-up Rear
9807-10 Wire
9818-5 Cast
23-1512
11.5”
11.5”
Note: 2000-up brake discs have 2.25” inner diameter cen-
ter hole, 1979-99 brake discs have 2.062” inner diameter
center hole.
10” Polished Razor Brake Discs.
VT No. Fits
Style
23-0847 Rear, Left
1973-80
23-0848 Rear, Left, 23-0848 has chrome center.
1973-80
Polished Stainless Steel Razor Brake Disc features full
stainless construction polished to high gloss. Order screw set
separately.
Rear, 11.5”
VT No. Year
Side Wheel Screw Set Holes
23-0386 1993-99 Right Wire
9807-10 Countersunk
23-0820 As Above
Unpolished
23-0388 1979-99 Right Wire
8791-10 Tapered
23-0392 2000-up Right Wire
9807-10 Countersunk
Cast
9818-5 Countersunk
Front, 11.5”
23-0376 1984-99 Left Cast
8793-5 Countersunk
Wire
8794-10 Countersunk
23-0391 2000-14 Left
Cast
8793-5 Countersunk
Wire
8794-10
Countersunk
11.5” Dura Polished Brake Disc. *Note: Chrome center por-
tion.
VT No.
Year
Type
Style
Bolts
23-1500* 1984-99 Front
Hole
8794-10
23-1501 2000-up Rear
Slot
9807-10
23-1516 1986-99 Rear
Razor
9807-10
23-1500
11.5”
23-0598
11.5”
Stainless Brake Rotor
23-0694
23-3774
23-0534
