1984-E86 XL, 1984-85 FXE-FXEF, 1984-86 FXR-XRS-
FXRDG-FXRC, except sport package. 35mm.
24-0016 Stock 23¹⁄₄”, Hard Chrome
24-0430 2” over stock, Hard Chrome
1983-86 FXRT-FXRD, 1984-85 FXSB, 1985-86 FXRS
with sport package. 35mm.
24-0430 Stock 25¹⁄₂”, Hard Chrome
Late1986-87 XL, 1987 FXR-FXRS models with showa fork
except FXRT-FXRD. 35mm.
24-0434 Stock 23³⁄₈”, Chrome
39mm
1988-94 FXRT, 1987-94 FXRS-SP. 39mm.
24-0019 Stock 25³⁄₈ , Chrome
24-0439 2” over stock,Chrome
24-0442 4” over stock, Chrome
1987-94 FXLR, 1988-94 FXR-FXRS 39mm, 1991-05 FXD,
FXDL
24-0020 23³⁄₈”, Hard Chrome, Stock
24-0437 23³⁄₈”, Chrome, Stock
24-0019 25³⁄₈”, Chrome, Stock
24-0439 27³⁄₈”, (+2”) Chrome
24-0442 29³⁄₈”, (+4”) Chrome
35/39mm Fork Tubes
39mm Fork Tube Assembly includes internals with springs,
assembled for 1987-99. Tube length is 24¹⁄₄”.
VT No. 24-0107
24-0107
41mm Fork Tube Set
1997-13 FLT, FLHR, FLHT 2000-17 FXST, FLST, 2000-05
FXDWG 41mm.
24-0045 20⁷⁄₈” Replaces 45890-97
Chrome
Stock FLT Length
24-0053 22⁷⁄₈” Replaces 45930-00
Hard Chrome
Stock FLST Length
24-0047 24¹⁄₂” Replaces 45417-00
Chrome
Stock FXST-FXDWG Length
24-0048
As Above
Hard Chrome
24-0055 24⁷⁄₈
" As
Above
Chrome
24-0049 26¹⁄₂ As Above
Hard Chrome
24-0056 26⁷⁄₈ Above
Hard Chrome
24-0050 28¹⁄₂ As Above
Hard Chrome
24-0058 30⁷⁄₈ As Above
Chrome
24-0052 32¹⁄₂ As Above
Chrome
24-0072 36¹⁄₂” As Above
Chrome
24-0073 38¹⁄₂” As Above
Chrome
24-0074 40¹⁄₂” As Above
Chrome
1984-96 FLT, FLHT; 1984-99 FXST-FXSTC, 1986-99 FLST-
FLSTF, FLSTN, 1993-99 FXDWG, 1985-86 FXWG, 41mm.
24-0411
20⁷⁄₈” Replaces 45824-84 Stock Chrome
FLT length
24-0027
As above
Hard Chrome
24-0461 22⁷⁄₈” Replaces 45930-86
Chrome
Stock FLST Length
24-0412 24¹⁄₄” Replaces 45417-00
Chrome
Stock FXST, FXDWG Length
24-0021 24¹⁄₄”
Hard
Chrome
24-1353 24⁷⁄₈” As Above
Hard Chrome
24-0413 26¹⁄₄” As Above
Chrome
24-0463 26⁷⁄₈”
Chrome
24-1354
As Above
Hard Chrome
24-0414 28¹⁄₄” As Above
Chrome
24-0472 32¹⁄₄” As Above
Chrome
24-0485 34¹⁄₄” As Above
Chrome
24-0487 36¹⁄₄” As Above
Chrome
24-0493 38¹⁄₄” As Above
Chrome
24-0494 40¹⁄₄”As
Above
Chrome
24-0961
Hard Chrome
Polished Chrome
Attention!!
These fork tubes have been manufactured and tested for exact fit and applica-
tion per model. It can be difficult to identify the front end assemblies because
they may not always be original equipment. Before installing, compare old and
new tubes. Be sure the stock top plugs fit into the new fork tubes. To avoid
scratching the chrome, we suggest that the tubes be lightly rubbed with oil
before installing into fork legs. Be absolutely sure you have the right tubes
before you install them. No fork tubes can be accepted for return that are
scratched or damaged due to improper installation or handling.
41MM Fork Tube Assemblies are hard chrome finish.
Include top plug, springs, spacers and internal pieces com-
pletely assembled. Order bushing set separately.
1984-99 FXST,1984-96 FLT, 1986-99 FLST, 1993-99
FXDWG
AEE (Chrome)
Dura (Hard Chrome) Length
24-0354
24-0960 24¹⁄₄”
Stock FXST, FXDWG Length
24-0356
24-0961 +2”
24-0357
24-0962 +4”
24-0358
+6”
24-0359
24-0964 +8”
24-0509
+10”
24-0551
+12”
24-0577
24-0967 +14”
24-0968 +16”
Leg Sets
VT No.
Length
FL 1977-84
24-0028 20¹⁄₂”
FLH 1949-76
24-0032 20”
FXWG 1980-83
24-0029 24¹⁄₂”
FLST 1986-99
24-0070 22⁷⁄₈”
Bushing Set
24-0097
49mm Fork Tube Sets with hard chrome finish.
2006-17 All Dyna models (except FXDF).
VT No. Fits
24-1185 Stock FXD 25
1
/
2
”
24-1186 Stock FXDWG 27
15
/₁₆”
24-1064 +2” As Above 29
1
/
2
”
24-1065 +4” As Above 31
1
/
2
”
24-1066 +6” As Above 33
1
/
2
”
2008-17 FXDF
24-1187 Stock 25
1
/
2
”
2014-17 FLT models
24-1188 Stock 22
3
/
4
”
24-1188
24-1185
