Dyna 2000 Digital Ignition Systems. Systems include Dyna
2000 HD-1 Ignition Module and a matched Dyna Twin Fire Coil
for each application.
VT No. #
Fits
32-0802 SFK-3 1996-99 FXST, FLST, 1996-98 FXD, L94-98 FLT
32-0804 SFK-1 Pre1991-95 FXST, FLST, 84-94 FXR, 91-94 FLT
Dyna 2000 Ignition Modules Replacement can be used
with stock electronic ignition.
Note: The stock ignition consist of a sensor plate and
rotating cup. The 2000 will work on all 1970-up models but
requires the 1983-up type ignition cup and sensor plate. The
2000 Advance curves will not work properly if installed with
the pre1983 ignition cup and sensor. Dyna 2000 HD-1 can be
used with both single fire (separate coils) or Dual fire (Single
Coil). The Dyna 2000 HD-2 can be used as dual fire only.
Both units feature programmable advance curves,rev limiter
and LED diagnostic lamp for easy static timing and plugs
into stock harness and bolts to stock module location. Also
available with USB port that will allow mechanics or tuners
more advanced programming but requires separate purchase
of Dyna Programming kit.
Note: Can only be used with sup-
pression spark plug wires. On 1984-90 models Dyna exten-
sion harness must also be used.
VT No. Item/Plug
Years
32-9113 Dyna 2000 HD-2E, 7 Pin
1984-95
with USB Port
32-9114 Dyna 2000 HD-1E, 8 Pin
1996-99
with USB Port
32-1074 DD2000-HD7EFI 2010-16 FLT with EFI
32-1075 DD2000-HD8EFI 2007-11 FXST, FLST with EFI
32-1076 DD2000-HD9EFI 2012-up FXST, FLST with EFI
32-9087 Ignition Cup Only
32-9020 Sensor Assembly
32-9052 Cup Screw, 10 pack
32-9117 Programming Software for 32-9113
32-9118 Programming Software for 32-9114
32-9119 Programming Software for TC 88-2P
Dyna Twin Fire Ignition Coils are designed to work with
Dyna 2000 HD-I ignition modules. Twin fire coils are slightly
larger than stock coils and fit the stock mounting bracket.
Twin fire coils can be used with any electric advance ignition
system that incorporates dwell control except Dyna DS6-2 or
similar type ignitions.
VT No. Dyna
Ohms/Type
32-9285 DC6-5 3 (A)Twin Fire II Miniature Dual Output
Towers, Replaces DC6-3
32-9264 DC6-4 3 (B) Four output towers
Fits Dual Spark Plug
Dyna Application
DC6-5 All FXR-FXST and Dynaglide models
DC6-4 Dual Spark Plug Head Application
32-9285
32-9264
Ignition
VT No. Fits
32-9501 Dual Fire Ignition fits Evolution, Shovelhead and
Sportster through 1997. It can be set for Street or
Race-Electric Start or Kick Starter. Includes 4000 to
8000 adjustable RPM limiter and adjustment for rate of
advance. This unit is compatible with stock dual fire
coils.
32-9500 Single Fire Ignition fits Evolution, Shovel and Sportster
through 1997. It can be set for Street or Race-Electric
or Kick Starter includes rear cylinder timing adjustment
for rate of advance. Compatible with single fire coils.
32-9503 Single Fire Ignition Kit fits As Above
Includes coil and 8.5mm wires.
32-0588 8.5mm Wire Set
32-9500
32-9501
Notes for installation:
32-9501
Red = Positive (coil)
Black = Negative (coil)
Brown = Tach
White = Topped Up (not used)
Green = Voes (vacuum switch)
Notes for installation:
32-9500
Red = Positive (coil)
Black = Negative (front cylinder coil)
White = Negative (rear cylinder coil)
Green = Voes (vacuum switch)
Brown = Tach
Important Note:
Some items on this page may be emission-related parts subject to California or other emission control laws. Please
see note for important information regarding emission control regulatory compliance and warranty information.
S&S H1-4N Multi Function
Performance Ignition features one
piece machined aluminum housing, BCD
switches with solid detent and legible
markings, which allows easy adjustments
of mode. Advance rate and rev limit, sin-
gle or dual fire operation and initial timing
marks that allows precise adjustment.
Fits 1970-99 XL. Also available as an
ignition kit which includes HI-4N ignition,
single fire coil and 8.5 mm plug wire set.
Unilite Breakerless Ignition System for all
1970-99 Twins. Unilite Dual fire module fea-
tures integrated photo coupler, signal proces-
sor and power switch. Requires mechanical
advance assembly and ignition coil with 3.0
to 4.0 ohms.
Ignition Module Adapters allow use of seven pin module
(1991-93) going to eight-pin Deutsch (1994-99) wiring harness
or an eight pin module going to a seven pin harness. Cannot
be used on electronic fuel injected models.
VT No. Fits
32-0085 7 Pin Adapter to 8 Pin Module
32-0086 8 Pin Adapter to 7 Pin Module
32-0085
32-0086
32-1732
32-9113
VT No.
Item
32-5119
Ignition System
32-7510
Mechanical Advance
V-Tech Ignition Systems fit all 1970-98 carbureted models
and requires sensor cup for 1982 and earlier applications.
Order tach interface, sensor cup and screw separately if
required.
Note: Order Coils As Required.
VT No. Item
32-1731 HI-4N Ignition
32-1732 HI-4N Kit
