352
Starter Shaft Kit includes parts pictured for Big Twins.
VT No.
Type Year
32-9238 V-Twin 1989-93
32-9288 Kit 1989-93
32-9200 Kit
1994-17 FXD, 1994-up FXST, FLST, FLT
16-1297 Tool Wrench
32-9200
Starter Shafts and Spacers.
VT No. OEM
Fits
17-9944 33120-85 1986-88 FLT-FXR
17-9939 31482-86 1986-89 FXST
17-9985 31311-80 Spacer, FLT
17-9984 33121-79 Spacer, FLT
17-0081 31493-67 Nut, FLT
12-0569 31312-80 Nut, FLH Classic
17-0085
32-9288
32-9238
Starter Drive for Big Twin features high strength five roller
clutch, stainless steel springs, hardened ramped clutch receiv-
ers, premium internal bronze bushing and factory pre-lubing.
VT No. Item
Fits
Brand
32-0638 31443-65A 1965-88 Accel
Heavy Duty
32-0639 31443-65A 1965-88 Volt Tech
32-2506 31443-65A 1965-88 Volt Tech
Heavy Duty
32-1561* 31544-90 1989-90 V-Twin
32-9031* 31663-90 1991-up V-Twin
32-9122* 31663-90 1991-06
32-0943
2007-up
*Note: Drive Assemblies
Starter Drive
Starter Clutch Drive Kits for Big Twin include clutch drive,
O-ring, lock tab, seals, spring and cable boot.
VT No. Year
32-0962 1991-92
32-0963 1993
32-0961 1994-17 FXD, 1994-up FXST, FLST, FLT
Starter Shaft Kit
includes parts
shown, drive includ-
ed. Fits 1994-up
FXST.
VT No. 32-9203
32-9031
32-0638
32-0639
32-2506
32-9122
32-1561
32-0943
Inner Primary Bearing Kit for Late 1985-up Big Twins
includes bearing, seal, two snap rings and one inner race.
1985-93 1994-05 2006-07
2008-up
12-0589 12-0591
17-0871
17-0873
17-0870 1985-05 Bearing/Sleeve
12-0589
12-0591
17-0871
17-0870
Starter Shaft
32-0961
32-0962
32-0963
17-0873
Inner Primary Cover Bearing and Seal Remover
Installer Tool safely removes and installs inner primary
bearing (OEM# 9135) without damage to the new bear-
ing by pushing on the outer perimeter of the bearing.
Removes and installs inner primary and seal that the
transmission mainshaft passes through (OEM#12052A).
For L1984-06 FXST/FLST; 85-up FLT/FLHT/FXR/FXD/
FXDWG.
VT No. 16-1027
16-1297
