390
Keihin Carburetor Rebuilds
contain needle, proper o-rings
and diaphragm.
VT No. Year
Brand
35-0200 1976-78
GB
35-0240 1976-86
Keihin
35-0196 1983-89
GB
35-0219 1976-86
James
35-0416 1989-up CV GB
35-0422 1988-up CV James
35-0200
Deluxe Carburetor Kits include
all pieces shown for 1976-89
Keihin carburetors.
VT No. Type
35-9172 Stock
35-9176 Viton
35-9279 Replica
35-9279
Carburetor Mount Stud Set replaces
29254-78. Fits 1978-89. Length is 1¹⁄₄”
VT No. 12-2110
Keihin Low Speed Jets fit 1976-89 Keihin car-
buretors, except CV.
VT No. OEM
MM
35-0297 27896-79 .65
35-0294 27894-78 .68
35-0296 27897-78 .72
35-0295 27382-77 .75
35-0299 27348-77 .88
35-0298 27348-76 1.00
Keihin Main Jets.
VT No. OEM
MM
35-0357 27419-76 1.65
35-0358 27418-76 1.70
35-0359 27417-76 1.75
35-0361 27416-76 1.80
CV Keihin Carb
Keihin Carburetor
Fitting replaces
27371-76, 90°,
plastic, each.
VT No. 40-0534
Adjustable Idle
Mixture Needles
provide adjustment
for Keihin carbure-
tors. Fits CV type.
VT No. 35-0130
High Flow Fuel Inlet replac-
es broken fuel inlet to the
carburetor bowl for modi-
fied engines. Fits all Keihin
carburetors (Butterfly and
CV) 1976-up Shovelhead,
Evolution, TC-88.
VT No. 35-0134
35-1972
35-0130
VT No.
Type
35-1972 ThunderJet Bendix Keihin, S&S E series
35-1976
ThunderJet for CV. Carburetor
35-0179
ThunderJet for S&S G & D Carburetor
Slow Jet Screw
Driver facilitates
removal of Keihin
slow jets with no
damage to jet.
VT No. 16-0546
Keihin Adjustable
Main Jet. Full
adjustability for
maximum tuning
efficiency.
VT No. 35-0369
35-1976
Keihin Carburetor Parts and Accessories
VT No. # OEM Item
14-0921 A 27121-89 Float Valve O-ring 1989-up CV
35-0110 B 27311-76 Pump cap, 10 pack
14-0566 27312-76 Float Bowl Screw O-ring, 1976-77
13-9234 C 27314-76 Throttle Stop Screw Spring
14-0560 D 27324-83 Float bowl O-ring 1983-91 CV, 5 pk
35-9067 E 27337-76 Float valve with clip 1976-82
27338-76
35-0230 F 27585-88 Vacuum Piston
14-0559 G 27358-76 Float bowl O-ring 1976-78
35-9066 I 27361-76 Pump diaphragm
35-0852 I 27361-76 Pump diaphragm (5 pack)
13-9168 27362-76 Diaphragm spring
14-0564 K 27577-88 Float bowl O-ring 1989-91 CV
14-0937 K 27577-92 Float bowl O-ring 1992-up CV
14-0557 L 27889-78 Float bowl O-ring 1978-82
14-0679 M 27385-76 Low Speed Jet Plug 1976-up
13-9212 27123-89 Accelerator Rod Spring 1989-up
13-9169 27136-81 Throttle and Idle Adj. Screw
Spring, 1981-up
13-0500 27136-90 Idle Screw Spring 1990-up
13-9213 27162-89 Vacuum Piston Spring, 1989-up
13-9179 27315-88 Primary Starter Spring, 1988-up
13-9181 27319-76 Low Speed Adjuster Screw
Spring, 1981-up
13-9183 27322-76 Throttle Lever Spring, 1981-up
13-9178 27584-88 Primary Vacuum Spring, 1988-up
35-9111 27886-78A Needle for CV 1983-up
35-9196 N 27576-92 Float 40 mm CV 1992-up
35-0230
Needle Jet Seat Cutter eliminates gaso-
line seepage from around the needle jet.
Creates a smooth and concentric seat
VT No. 16-0095
Important Note:
Some items on this page may be emission-related parts subject to California or other emission control laws. Please see
note for important information regarding emission control regulatory compliance and warranty information.
ThunderJet Accelerator Jet
& Accessories mounts in all
Bendix-Keihin, S&S, flowmaster,
Tillotson, and CV carburetors.
Choke must be deleted for use.
Works on Venturi vacuum princi-
ple as third jet. Extra jets included.
