413
BIG TWIN
1996-up Softail Bo bbed Dash Components.
VT No. OEM
Item
39-0467
1996-99
39-0101 71254-96 1996-99 Dash Only
39-0896 Kit
1996-99 Chrome Dash Panel with Switch
Component Listing
37-0555
7497
Acorn Lock Nut, 1996-up
33-0134
53439-79
Bulb Back Light, 1996-up
39-0449
67033-99
MPH Speedometer, 1999-03
28-0139
67190-89
Speedometer Seal, 1989-up
39-0179
67880-94
Reset Switch Boot, 1994-up
33-0137
68024-94
Indicator Lamp Bulbs, 1994-98
39-0180
71302-93
Switch Name Plate, 1994-17
32-0439
71313-96
Ignition Switch, 1996-up
32-0931
72191-94
Terminal, Socket
32-0936
73191-96
Socket Contact
Dash
39-0219
Speedometer Reset Knob fits 1998-up models. Replaces
67854-98.
VT No. Item
Model
39-0549 Reset Knob
All
39-0179 Reset Knob Boot
All
39-0564 Reset Knob Kit
39-0179
39-0549
Dash Board Rubber Strip closes the
gap between dash and tanks.
VT No. Fits
Type
Model
28-0543 1968-94 Dash
Big Twin
28-0554 1988-92 FXRS
FXR
28-0540 1977-84 FXS Type FX
39-0896
Installed
with 39-0453
32-0439
39-0453
39-0449
39-0896
39-0564
Chrome Speedometer Sensor Block-Off
Plate Kit includes plate, gasket and mount-
ing screw for 1996-up Softail.
VT No. 17-0234
Programmable Transmission Speedometer
Sensor is a fully adjustable sensor assembly for all
5 and 6 Speed transmissions with electronic drive
speedometer. It allows fast and accurate adjustments for any
tire size, pulley size on gear ratio change.
VT No. 36-0150
Speedometer Sending Unit Wrench features a shortened ³⁄₁₆”
ball end hex bit for removal or installation of hex screws used
on all Big Twin models equipped with electronic sending units.
VT No. 16-6738
Speedometer Sensor
Speedometer Calibrator
Corrects readings of stock
electronic speedometers when
using oversized rear tires or
when other drive train modifi-
cations have been done that
effect final drive ratio. Use on
all Big Twins.
VT No. 36-0422
36-0422
39-0467
LED Dash Cover Chrome fits 1968-1984 FL.
VT No. 39-0219
