446
Chrome Rear Axle Nut Kit is a custom hard-
ware kit with installation instructions. Fits 1973-
up Big Twin.
VT No. Style
8606-6 Acorn
8607-6 Cap
Chrome Rear Axle Spring Clip replaces 510
spring clip used on all 1991-up FL, FX, XL.
Sold as pack of 5.
VT No. 2042-5
Chrome Castle Nut Kit includes washer and cot-
ter pin for rear axles on 1989-up models. Replaces
7987, 511.
VT No. 37-9032
Chrome Axle Parts for 1972-79 FL-FLH,
1973-79 FX-FXE-FXS, 1952-79 Sportster.
VT No.
Item
U/M
44-0326
Nut with washer
Kit
37-8127 Nyloc-Nut
10
44-0749
Nut Washer
1
44-0326
8606-6
37-9032
Axle Nut
Chrome Rear Axle Spacer Kits. FX-FLST Kits include left
side spacer, two axle adjuster collars and castle nut. Kits for
Dynaglide include castle nut for axle and adjuster collars.
Stock Grooved Years
For FXST Models
9810-4
— 1987-99
2026-5
— 2000-07
2026-5T
—
2000-07
2512-7
—
2008-17
For FXD Models
9812-3
— 1991-99
2038-4
2037-4 2000-05
2335-5
— 2006-07
2516-5
—
2008-up
Rear Axle Spacer
2038-4
2037-4
DIY Universal Axle Spacer is constructed of
stainless steel 6” long to be cut to length.
VT No. Inner Diameter
44-0670 ³⁄₄”
44-0753 1”
Rear Axle Spacers allow wheels with 1” or 25 mm inner
diameter bearings to fit ³⁄₄” axle.
VT No. Length
44-0788 1¹⁄₈”
44-0690 1¹⁄₁₆”
44-1978 1”
Rear Axle Spacers.
Chrome Zinc
# Application
44-0325
44-2051 A 1984-86 FXST cast/wire wheel
1973-82 All FL’s left cast/wire,
1973-83 FX-FXE-FXEF
FXEF-80-FXWG left wire wheel
1981-86 FXE-80 wire wheel
1973-86 All FX cast wheel
44-0342
44-0345 B 1986-99 FXST-FLST
44-0655
C 1982 only Classic 1983-up FLH-80
Cast or wire, 1984-86 FXWG wire
1980-86 FXB-FXSB cast wheel
44-0659
44-0341 D 1982-up FXR left side cast/wire
1985-up FXRT cast wheel
44-0227
44-0374 E 1990-99 FXD
44-0813
—
2000-07 FXST
44-0788
44-0690
44-1978
A
B
C
D
E
Rear Axle Seal Spacer Sets.
VT No. Application
44-0421 1982-86 FXR’s cast/wire wheel pairs
1984-86 FXST wire wheel, 1982-86 FXWG wire wheel
1982 only FXS-80, wire wheel
1982-86 FXB-FXSB cast wheel
44-1944 As above with lip
44-0427 1987-99 FLT-FXST-FXR
44-0427
44-0421
44-1944
Axle Spacers feature ³⁄₄” inner diameter for front or rear
wheel use.
Sets
Each
Length Finish
—
44-0937
.560” Chrome
—
44-0879
³⁄₄
” Chrome
—
44-0342 1.25” Chrome
—
44-0325
²⁷⁄₃₂
” Chrome
44-0729 —
¹⁄₈
” Chrome
44-0730 44-0253
¹⁄₄
” Chrome
44-0731 —
³⁄₈
” Chrome
44-0732 —
¹⁄₂
” Chrome
44-0733 —
⁵⁄₈
” Chrome
—
44-0877 .650 Chrome
44-0734 44-0430
³⁄₄
” Zinc
44-0735 44-0254 1”
Chrome
44-0737 —
1¹⁄₄” Chrome
—
44-0786 1⁵⁄₈” Zinc
44-0736 44-0429 1¹⁄₂” Zinc
—
44-0659 1³⁄₁₆” Chrome
—
44-0227 1⁷⁄₁₆” Chrome
—
44-0658 1¹⁵⁄₆₄” Chrome
Axle Locator Set allows use of ³⁄₄ axle in stock
rigid frames with ⁷⁄₈” axle slots.
VT No. 44-1946
9811-3
9810-4
2026-5
44-0658
44-0729
44-0731
44-0735
44-0735
44-0879
