Custom Rear Axle
Note: Rigid types have a milled head to fit replica rigids.
VT No. Item
Length
Rigid
44-0221 Kit
10.25”
44-2038 Kit
11.75”
44-1951 Axle 10.25”
44-0230 Axle 10.75”
44-2043 Axle 11.75”
44-1985 Axle 11.25”
44-1986 Axle 12.
.
25”
44-1942 Axle 12.50”
Swingarm
44-1945 Axle 11.50”
44-0947 Axle 12”
44-1044 Axle 12.50”
Rigid Frame Disc Brake Rear Axle for use when 1973-up
rear disc brake units are installed on rigid frames. Kit includes
.750” diameter axle, nut, special spacer and washers. Other
axles sold separately. Spacers may have to be cut to length.
Rigid axles have milled area on hex head. Swing arm does not.
Length includes threads not head.
44-0221
Axle Collar Sleeves have milled flat section on
one end to fit rigid frame slots.
VT No. Length U/M
44-0394 1
5
/
16
” Pair
44-1987 1
13
/
16
” Each
44-1988 2
3
/
4
” Each
44-0316
Sleeve Collar
44-0520
Nut
44-0394
44-1951
Chrome Rear Axle Nut and Washer Kit
includes two extra thick washers, nut and
lock washers for 1973-up, on square swing
arms.
VT No.
Brand
8715-4
Colony
44-0520
V-Twin
44-0520
44-0230 Milled Flats
Rigid Head Detail
Axle Locator Set allow use of ³⁄₄ axle in
stock Rigid frames with ⁷⁄₈” axle slots.
VT No. 44-1946
³⁄₄
” Threaded Axles feature 1 inch of ³⁄₄” — 16 UNF thread at
each end. Use with acorn, pike or nyloc nuts as required.
VT No.
Item
Length
44-0667 Axle
12¹⁵⁄₁₆”
44-0638 Axle
13.5”
44-0646 Axle
14.0”
44-0148 Axle
14.5”
44-0652 Axle
15.0”
44-0149 Axle
16.0”
37-0889 Acorn Nut Set
44-0647 Pike Nut Set
Custom Rear Axle for 1986-99 Softail models. Include ³⁄₄” x
14.5” axle.
VT No.
Style
44-0645 Pike
44-0656 Acorn
44-0656
44-0645
44-0647
37-0889
44-0667
37-8885
37-8884
44-0741
2536-2
37-0999
44-0742
Axle Nut Cover
Chrome Axle Nut Caps Set for both axle nut and axle head
where required. Each cap has an internal hex to allow more
thickness for the set screws thread to eliminate thread stripping.
Note: These axle caps will not work on late model rear axles
with cotter key locking devices.
Front
Rear
Fitment
—
37-8885
1984-94 FXST
Does Not Fit Rear 1989-94
—
37-8885
1982-87 FXR
—
37-8885
1981-85 FX
—
37-8884
1973-80 FX
—
37-8886
1971-72 FX
—
37-0041
2000-07 Softail
—
44-0742
2008-up Softail
44-0741 —
2007-up FXST
37-0999 —
2007-up FXST for 25 mm axle
2536-2
—
2007-up FXST
37-0999 —
2008-up Touring for 25 mm axle
—
44-0845
2006-07 FXD
—
37-8885
1980-94 FLT
Does Not Fit Rear 1989-94
37-0041
Wheel Bearing Adapter Sleeves
to adapt 3/4” axles to later hubs.
VT No.
Fits
44-0054 25 mm
44-0055 1”
44-0054
44-0055
