459
BIG TWIN
Rear Wheel Rim
Rear Wheel Rims feature drop center design for bead and 40 spoke holes. Available in black, chrome or raw. Note: Large hole
accepts rubber valve stem tube. Small hole accepts metal stem tubes.
*Note: Rim has small center valve stem hole all other
numbers have small side valve stem hole.
16” Rim with Small Valve Stem Hole
52-0230* 3.0” Perma
Chrome
52-0222 3.0” Perma Chrome
52-1023 3.0” Perma
Black
52-0691 3.5” Perma Chrome
52-0228 4.5” Perma
Chrome
52-0430* 5.0” Perma
Chrome
52-0472* 5.0” Perma
Black
18” Rim with Center Hole
52-0707 2.50” V-Twin Chrome
52-0229 4.25” Perma
Chrome
17” Rim with Center Hole
52-0435 4.5” Perma Chrome
52-0896 6.0”
Perma
Chrome
*Note: Rim has small center valve stem hole all
other numbers have small side valve stem hole.
16” Rim with Large Valve Stem Hole
VT No. Width Brand
Finish
52-0226 3.0”
Perma
Chrome
52-0699 3.0” Perma Raw
52-0692 3.0”
Perma Black Gloss
52-0223 4.0”
V-Twin Chrome
52-0303 4.0”
Replica Chrome
52-0229
52-0435
52-0692
52-0226
Replica Drop Center Front Rims.
19”
Chrome Black
OEM
Width Brand
52-0700
52-0234
43018-73
2.5”
Perma
52-0713
43018-73 2.5” DW
52-0752
43001-06 2.5” Perma
52-1043 41427-07
Perma
52-1041
52-1214 43001-06 3.0” Perma
21”
52-0748
52-1208 2.15”
52-0788
3.25”
23”
52-1291
3.00”
Perma
52-0752
52-0700
Front Chrome Rim and Spoke Kits fit hubs
as noted. Note: For use with steel hub.
VT No. Size
52-0300 3.00” x 16”
52-0301 2.50” x 19”
52-0302 1.85” x 21”
52-0303
52-0230 Shown Center Valve Stem Hole
Front Wheel Rim
52-0788
Front Smoothie Wheel Rims feature a smooth profile with
chrome on aluminum construction.
VT No. Size
52-0790 16” x 3.00”
52-0791 21” x 2.15”
52-0791
52-0790
Side
Valve
Hole
52-0896
52-0430
VT No.
OEM
Size
52-0702
43001-79
19” x 2.50”
52-0701
43662-80B
21” x 2.15”
52-0748
Replica
21” x 2.15”
52-0702
52-0701
Deluxe Chrome Front
Wheel Rims are roll
formed of high strength
steel and finished with a
deluxe chrome finish. Both
are drop center style with
the rolled-edge design for
added strength.
52-0707
52-0230
80 Spoke Chrome Rim Only
52-0212 1.85” x 21”
52-0704 3.00” x 16” with small stem hole
52-0705 4.00” x 16” with large stem hole
WM Type Rim
WM1 = 1.6”
WM2 = 1.85”
WM3 = 2.15”
52-0699
Center
Hole
52-0212
