513
CLASSIC
Knucklehead
Knucklehead Rocker Parts. Order strip set with gaskets separately.
VT
No.
Item
Finish
42-0863 Cover Set, Replica
Chrome
42-0854
Cover
Set
Parkerized
7517-8 Cover Strip and Gasket Kit
Zinc
7517-8T As Above, V-Twin
42-0864 Cover Strip and Gasket Kit
Parkerized
42-0983 Cover Strip and Gasket Kit
Chrome
15-0270 Cover Gaskets Only
37-0565 Cover Screw, 34 pieces
Parkerized
2955-34 Cover fillister head slotted screw kit for 1938 61"
3023-34 Cover hex head screw kit
Chrome
3024-34 Cover hex head screw kit
Cadmium
3025-34 Cover hex head screw kit
Parkerized
49-1791 Box Cap and Fitting
Brass
49-1793
Clip
Parkerized
49-1865 Washer
49-1336 Seal Kit,1936-37
49-1866
Seal
Graphite
VT No.
Finish
Year
42-3637
Parkerized
1936-37
42-6174
Parkerized 1938-47
42-6175
Chrome 1938-47
49-1319
Line Set
1938-47
42-3637
42-6174
V-Twin Replica
TM
Knucklehead Head Set feature original cast iron
with black heat paint finish. Available as bare heads that have valve
seats installed only, assembled heads that have guides, springs, collars,
valves and parkerized lower tins installed and completely assembled
that includes an assembled head set with rocker arms, rocker boxes and
upper cover set installed with correct hardware All sets include intake
manifold nipples installed.
VT No. Fits
Type
11-1285 1941-47 Bare Front Head Only
11-0850 1941-47 Assembled Head Set
11-0857 1941-47 Fully Assembled Head Set w/Parkerized Top Covers
11-0858 1941-47 Fully Assembled Head Set w/Chrome Top Covers
11-0891 1941-47 Fully Assembled Head Set w/Parkerized Top Covers
and 1936-39 type Rocker Boxes and Tins
49-1310 1938-39 Bare Head Set
49-1345 1938-39 Fully Assembled Head Set w/Correct Rocker Boxes
49-1345A 1936-37 Bare Head Set
49-1347 1936-37 Fully Assembled Head Set w/Correct Rocker Boxes
Replica
TM
Knucklehead
Top Oiler Line 1936-47 Knucklehead.
1936-41 is banjo type. 1942-47 is flared nut type in tin or chrome finish.
VT No.
OEM
Year
Item
Finish
40-0240
3573-36
1936-41
Banjo line
Tin
40-0247
3573-36
1936-41
Banjo line
Chrome
40-0518 63578-36 1936-41 Banjo Bolt, each
Cadmium
9848-9
Kit
1936-41
Banjo Nipple Kit
Cadmium
with banjo bolt and washer
9847-9
Kit
1936-41
As Above
Chrome
14-0154
6440
1936-41
Washer for above, 10 pack
40-0112
63480-42
1942-47
Oil Line
Chrome
40-0239
63480-42
1942-47
Oil Line
Tin
8941-3
17330-42
1941-47
Line Fittings
Cadmium
17325-42
3 piece set
7349-3
As above
Chrome
8630-1
33615-36
1936-41
Line Fitting
Cadmium
For Timing Cover
9738-1
33615-36
1936-41
As Above
Chrome
9847-9
1936-41
Line Fitting Kit Chrome
9848-9
1936-41
Line Fitting Kit
Cadmium
Note: Nut type ends.
Knucklehead Lower
Valve Spring Cup Sets
include parkerized 4
piece set of lower cov-
ers with oil lines and
nuts attached. Kit also
includes rocker cover
strip set with screws in
parkerized finish and
chrome or parkerized
cover set with gaskets.
1941-47 Braided Top
Oil Line
VT No. 40-0197
40-0197 Installed
11-0850
1940-47 Knucklehead Oil Filter and
Bracket Kit includes oil filter assembly with
polished top and chrome canister body and
zinc plated mount bracket. Order oil lines and
fittings separately.
VT No.
Item
40-0564
Oil Filter Kit
40-0370
Oil Line Set, Cadmium
40-0107
Oil Line Set Chrome
40-0505
Fitting Set
40-0505
9848-9
40-0247
40-0239
40-0240
42-0863
42-0854
49-1319
11-0891
11-1285
Head Bolt and Washers for 1936-47 OHV Knucklehead.
Parkerized Cad
Chrome Fits
9725-20
7713-20 —
1936-39 with washers
—
—
8456-20 As Above Cap Style
9726-20
7714-20 8220-20 1940-47 with washers
2010-10
—
—
1936-47 OHV, Washers only
9725-20
7713-20
11-0891
11-0891
49-1310
