517
CLASSIC
Valve Spring Kit
Valve Keeper Keys are packaged and sold in
four pairs per package enough for one engine.
Fits 1936-85 Big Twin. Keys are split type.
VT No.
OEM
Brand
11-0513 18228-36 V-Twin
11-9616 18228-36 Manley
11-9623 18228-36 Sifton
Steel Valve Collars 61, 74 and 80 Big Twin.
VT No.
OEM
Use
Year
11-0515 18222-48 Lower 1948-79
11-0644 18221-36
Upper 1936-80
11-0516 18222-79
Lower 1980-Early 81
11-0666 18222-81
Lower 1981-84
11-0648 18219-81
Upper 1981-84
11-0712 18219-81 Upper 1981-84
11-1153 Sifton
Upper 1981-84
Valve Spring Kits include all springs, collars and keepers nec-
essary for each application.
VT No.
Year
Model
13-9193 1948-79 Pan-Shovelhead
13-9194 1980-81 Shovelhead
13-9195 1981-84
Shovelhead Big Twin
1948-84 Pan-Shovelhead Valve Spring Sets include inner
and outer.
VT No.
Fits
Replaces
13-0169
1948-84 18201-57B/18204-36A
13-0179
1966-84 18201-82/18202-82
1948-79 Lower Collar Seal Set includes
four seals (VT No. 14-0145) to use with
stock style guides.
VT No. 11-0874
13-0169
Andrews Valve Gear for 1966-84 Shovelhead 74 and 80.
VT No.
Fits
11-9877 Upper Collar, T-6 Aluminum for
.600 lift, 4 piece set
11-9878 Upper Collar, T-6 Aluminum, adds
.060” spring travel and is for medium lift
13-9250 Hi-Lift Spring Set
Valve Stem Seals in 10 packs for years listed. Installation tools
and plastic 10 pack sleeves available separately.
VT No.
Fits
Mfg. No.
14-0145 Big Twin 1948-78 1408
14-0146 Big Twin 1979-84 1427
14-0982 Big Twin 1948-78 Sifton
14-0375 Big Twin 1979-84 Sifton
16-1753 Sleeve
³⁄₈
”
Installation Tools
16-0133 1948-79 Big Twin Black
16-0134 1981-83 Big Twin White
Note: 14-0164 is ⁵⁄₁₆, 14-0145 and 14-0146 are ³⁄₈.
Sifton Valve Stem Seal features a Viton seal with double
coil spring for tension, and steel band to secure to guide. Fits
1948-84 Shovelhead.
VT No. 14-0973
Valve Stem Oil Seal Kits include four pieces of proper guide
seal and installation tool.
VT No. Year
16-0403 1948-79
16-0404 1980-84
Valve Guide Seal
Sifton Veloprene Coated Valve Stem
Seal Set for Big Twin provide maximum
valve stem oil control as seals wipe excess
oil from the valve stem by means of a
unique spring loaded wiper assembly
which prevents unwanted oil from reaching
and contaminating the cylinder. Machining
required. Fits 1948-84.
VT No. 14-0259
13-9195
11-0515
11-0644
11-0516
11-0666
11-0648
11-0712
16-0403
16-0404
