Mechanical Brake
Mechanical Kit for 1936-57 Big Twin is perfect for finishing a
restoration or for forward controls on a custom rigid frame. For
use on mechanical brake frames with a cross shaft tube only.
Hardware is included. Footboards may be used with this kit.
VT No.
Type
22-0706 Chrome
22-0707 Parkerized
22-0668 Parkerized Note: Includes stop lamp switch kit
23-0666 Parkerized Cross Shaft Kit
9677-4T Nut Set
22-0171 Kit, Parkerized except pedal
22-0706
22-0706
Emergency Brake Lock fits mechanical brake pedals on Rigid
1936-57 Big Twins.
VT No. Item
23-1949 Complete
23-0055 Pedal and Plate Kit
23-0055
23-1949
Rear Brake Assembly for 1936 only fits 61” Overhead Valve.
Includes black brake drum, backing plate, rear brake cam, brake
lever, brake shoe set, brake shoe springs and pivot stud.
VT No. Item
49-0555 Rear Brake Assembly
49-0357 Backing Plate
49-5515 Black Drum Only
49-1344 Raw Drum Only
49-0613 1936 Rear Backing Plate
Wheel Lug Bolts for brake drums. Use tap 16-0807 for ³⁄₈ — 20.
Black Chrome OEM
Years
Fits
37-8675 23-0440 43530-35A 1936-72 ³⁄₈ — 20
37-8691 —
43530-35A 1936-72 ³⁄₈ — 20
— 37-8919 43531-35 Oversize ⁷⁄₁₆ — 20
49-0457 — 43531-35 1936-37 ³⁄₈ — 20
23-0090 —
43631-35 1936 ³⁄₈ — 20
23-0935 —
Set, Parkerized
22-0707
Brake Shoe Sets fit 1937-57 Big Twin Rigid and are complete
with linings installed. Sold in pairs. Note: When new shoes are
installed, they may have to be “arced”. VT No. 23-1795 shoe sets
are fit to our drums. Pivot Kit includes cam.
VT No. Type
Pivot Kit Pivot Kit
Cadmium Parkerized
23-0500 Stock
23-1830 23-1027
23-1795 Arced
23-1830 23-1027
23-1750* Cast
23-0986 23-1014
23-0504 Linings Only
*Note: Original Cast Construction
23-0504
23-0500
23-1750
23-1795
12¹⁄₈” long,
1⁹⁄₁₆” wide
22-0668
22-0171
Mechanical Brake Crossover Shaft Bushing Installation Tool
and Reamer allow bushing to seated in brake tube to proper
depth. Reamer will size bushing to correct I.D. for proper fit of
crossover shaft.
VT No. Item
2712-1 Driver
16-0878 Reamer
2712-1
16-0878
23-0666
Rear Brake Drum Kits feature backing plate with all compo-
nents installed, including a pre-arced set of brake shoes to fit
the drum supplied. The drum has the 51 tooth sprocket riveted
on with an original style dust ring. Kits are available in black or
chrome finish. Lug bolts included, but axle and sleeve kit must
be purchased separately.
VT No. Kit
23-0876 Black
23-0877 Chrome
23-0295 Black/Cast Drum
22-0981 Mechanical Drum Assembly, 1937-57
23-0876
VT No. Replica
Finish
22-0708 22-0745 Chrome
22-0709 22-0746 Black
22-0040 22-0074 Chrome
22-0041 22-0075 Black
22-0745
22-0746
23-0877
23-0295
49-0555
49-0357
49-5515
49-1344
Mechanical
Backing Plate
Kit for 1936-57
includes plate,
springs, shoes,
cam pivot stud
and plate. Arm
not included.
