CLASSIC
Chrome Adapter Fittings see listing for application.
*Note: Most common use
VT No.
Fitting Type Adapts To:
23-4047 10mm Banjo, Straight
23-4050 10mm Banjo, 35°
23-4055 10mm Banjo, 45°
23-4051 10mm Banjo, 90°
23-4052 ⁷⁄₁₆” Banjo, Straight
23-4053 ⁷⁄₁₆” Banjo, 35°
23-4056 ⁷⁄₁₆” Banjo, 35°
23-4054 ⁷⁄₁₆” Banjo, 90°
23-4057 12mm Banjo,Straight
23-4058 12mm Banjo, 35°
23-4059 12mm Banjo, 90°
23-4244 ¹⁄₈” Male NPT, Straight
23-4279 ¹⁄₈” Male NPT, 90°
23-4293 ¹⁄₈” Male NPT, 45°
23-4298 Male “T”
23-6033 Flare Union
23-6034 ³⁄₈”-24 Banjo Bolt
23-6035 ⁷⁄₁₆”-24 Banjo Bolt
23-6040 10mm x 1.25” Banjo Bolt
23-6041 12mm x 1.25” Banjo Bolt
23-6042 10mm x 1.25” Double Banjo Bolt
23-0746 ³⁄₈”-24 Brake Switch Banjo Bolt
23-6037 35° Rear Banjo, 10 mm
23-6038 90° Short Rear Banjo, 10 mm
23-6039 90° Long Forward Control Banjo, 10 mm
23-4396 ³⁄₈”-24 Male Inverted Flare, straight, 2 pack
23-4380 ³⁄₈”-24 Male Inverted Flare, 90° and 120°
*Junction block to master cylinder
23-4281 ³⁄₈”-24 Male Inverted Flare, 45°
*Rear Calipers
23-4282 ³⁄₈”-24 Male Inverted Flare, 90°, short
*Junction Block to Front Caliper
23-4283 ³⁄₈”-24 Male Inverted Flare, 90°, long
*Junction Block to Front Caliper
23-4284 ³⁄₈”-24 Male Inverted Flare, 150°
*Forward Controls
23-4306 Front Wide Glide Junction Block
23-4307 Front Narrow Glide Junction Block
23-4305 90° long forward control banjo, 10 mm
23-4303 35° short rear brake banjo, 10 mm
23-4304 90° short rear brake banjo, 10 mm
Universal Brake
Fitting & Bolt
23-4396
23-4051
23-4054
23-4244
23-4293
23-4298
23-4050
23-4053
23-4284
23-4047
23-4052
23-4281
23-4279
23-4283
23-4282
23-4380
Brake Banjo Seal Washers feature built in O-Rings.
VT No. Type
14-0567 ⁷⁄₈”, 12mm fits handlebar cylinders
1984-00, single disc
14-0568 ³⁄₈”, 10mm fits 1982-00 dual disc
Brake Calipers
14-0578 2001-up master cylinder and brake calipers
14-0048 2006-up Banjo Bolts
Allen Button Head Banjo Bolts are sold with
washers.
VT No. Size
MM
37-8517 ³⁄₈-24 10mm
37-8518 ⁷⁄₁₆-24 12mm
10mm Russell Street Legal Universal Brake Lines are build it
yourself line assemblies ready for adapter fittings. They are pre-
assembled with high performance #3 stainless braided hose with
a rugged veloprene coated inner, and crimp-on chrome plated
female swivel hose ends. Clear coated for abrasion resistance.
Meet the guidelines of the D.O.T. MVSS-106 requirements and
are 50-state legal, and compatible with all brake fluids.
VT No. Length
23-8352 4”
23-8002 6”
23-8010 9”
23-8020 12”
23-8030 15”
23-8362 16”
23-8040 17”
23-8212 18”
23-8050 19”
23-8060 21”
23-8070 23”
23-8080 25”
23-8090 26”
23-8100 28”
VT No. Length
23-8272 56”
23-8282 58”
23-8229 60”
23-8332 62”
23-8312 64”
23-8322 66”
23-5833 68”
23-5835 72”
23-5836 74”
23-5840 80”
VT No. Length
23-8110 30”
23-8120 32”
23-8130 34”
23-8342 36”
23-8140 38”
23-8242 40”
23-8150 42”
23-8252 43”
23-8262 44”
23-8192 45”
23-8372 46”
23-8160 47”
23-8202 50”
23-8170 52”
23-8180 54”
Chrome Banjo Bolts include seal washers.
VT No. Size
MM Style
2190-3 ³⁄₈ - 24
10 Dome
2191-3 ³⁄₈ - 24
10 Allen
2192-3 ⁷⁄₁₆ - 24
12 Dome
2193-3 ⁷⁄₁₆ - 24
12 Allen
2190-3
23-4303
23-4304
23-6033
23-4306
23-4307
23-4305
23-4055
23-8020
23-8002
23-8010
Chrome Banjo Bolt Kits are for use with uni-
versal or stock lines, front and rear. Washers
are included. The VT No. 37-8979 is to be
used when a master cylinder or caliper uses
a ³⁄₈-24 banjo bolt and the line has a 12mm
hole instead of 10mm.
VT No.
Line
Size/Item
23-0612 10mm
³⁄₈
-24
23-0613 10mm
Washers
23-0614 12mm
⁷⁄₁₆
-24
23-0615 12mm
Washers
37-8979 12mm
³⁄₈
-24 (Special Kit)
14-0568 10mm
Washer with O-Ring
14-0567 12mm
Washer with O-Ring
23-0612
