586
1972-84 Front and 1973-80 Rear Chrome
Caliper Cover Kit includes mount studs.
VT No. 42-0312
Caliper Mount Bracket and Anchor Arm is for FX-FL with a
10” rotor.
Chrome Black OEM
Year Item
23-2257 23-0841 44166-73 1973-80 Mount Bracket
23-9186
Special Rigid Mount Bracket
23-1729
44154-73 1973-82 Anchor Arm 12⁵⁄₈” length
23-0861
Special 1973-82 Anchor Arm 10⁵⁄₁₆” length
23-0111
1973-80 Caliper Support
VT No. Type
23-0578 Bushing for Pin
Caliper Mount Bracket for 11.5” brake discs
replaces 44027-82 and fits 1982-Early 87
FXST Big Twin with 11¹⁄₂” rotors only.
VT No. Finish
23-9033 Black
23-0898 Chrome
Chrome Clevis Pin replaces 40919-81 on
rear caliper bracket. It includes washer and
cotter for 1981-85 Big Twin.
VT No. 23-1749
1973-80 FLH-FXE Caliper Bracket will
accept stock 1981-82 caliper.
VT No. Size
Finish
23-0524 10” Chrome
23-0542 11¹⁄₂” Chrome
23-0801 11¹⁄₂” Polish
23-0524
Caliper Support Bar Bolts secure bar to
caliper bracket and swing arm on 1973-85
FX-FL models.
VT No. Finish
Brand
37-8135 Chrome V-Twin
9106-8 Chrome Colony
9107-8 Cadmium Colony
23-9186
23-0111
23-1729
23-0861
23-2218
23-2219
23-2217
23-2215
23-2240
Caliper Assemblies are fully assembled with disc pads and all
internals for rear FX-FL models and front FL models. Calipers
accept ¹⁄₈” NPT line.
Front
VT No.
OEM
Years
Finish
23-2219 44104-72A 1973-80 Black
23-2237 44105-72 1973-80 Chrome
Rear
23-2218 44105-72 1973-80 Black'
23-2205 44105-72
Black
23-2215 44105-72 1973-80 Chrome
23-2240 44105-72 1973-80 Chrome
23-2227 44011-81 1981-82 Chrome Dual Piston for 11”
23-9193 Kit
1981-82 For Above
23-2217 44011-81 1981-82 Black
23-3051 44011-81 1981-82 Chrome
23-3055 44050-82A 1982-86 Chrome
1973-82 Banana Caliper
23-2227
23-3051
23-9193 for 23-2227
23-3055
Rear Brake Caliper Guide Pin
Kit for 1982-Early 87.
VT No. Year
Model
23-0693 1982-87 FX
2855-7 1980-85 FLT
23-2237
2855-7
23-0693
Chrome Caliper Anchor Arm
for 1983-86 FL-FX models
replaces 41039-82.
VT No. 23-3065
23-3065
23-0841
23-2257
