589
CLASSIC
Single Caliper Pieces for 1974-77 FX.
VT No. #
OEM
Item
23-1723 K
44275-74 Piston
12-0943 L
44274-74 Piston, Friction Ring
23-0514 A&B 44281-74 Pad Set
23-0606 E&F 44277-74 Caliper Seal Kit
44278-74
23-0148
Kit
Service Kit includes C, D, E, F, G, N
23-1747 C&D 44280-74 Caliper Pin Set, Two piece
44283-74 Set
23-1995 H
44272-74 Anchor Arm
I
44276-74 Plate, Floating Lining
23-0065
—
Anchor Arm Only
37-8996 M
Kit
Mount Bolt Kit Chrome
23-1730 J
Complete Black Caliper Assembly with A-F+H,I
23-0711 N
41749-58 Bleeder Screw
8759-5 O
41191-74 Chrome Rotor Screw Set
Front Caliper Service Fix
Kit for 1974-77 includes seal
kit, spring, pins and bleeder
screw.
VT No. 23-0148
Caliper Kit for 1974-77 FX includes zinc or polished stainless
steel 11.5” brake rotor.
VT No. Disc
Rotor
Caliper
23-1003 Steel
Zinc Black
23-0564 Steel
Zinc Chrome
23-0565 Stainless Steel Polished Chrome
23-0564
23-0565
1974-77 Front Caliper
Clover Leaf Style 11.5” Brake Rotors for 1974-77.
VT No. Type
Finish
Brand
23-0302 Drilled Zinc
Dura
23-0303 Plain Zinc
Dura
23-0317 Drilled Stainless Steel
Russell
23-9042 Drilled Stainless Steel, Polished
Russell
23-0358 Drilled Stainless Steel, Polished
Dura
23-0636 Drilled Stainless Steel
Dura
Single Disc Caliper Kit for 1974-77 FX includes billet caliper,
11.5” drilled zinc plated steel rotor and mount bolts.
VT No. Item
23-0626 Kit
23-4513 Caliper and Bracket (GMA)
23-4513
23-0626
Single Disc Front Caliper Assembly for 1974-77 FX features
stock type construction in black or chrome with piston installed.
Caliper units include zinc plated brackets and hardware. Fits
11.5” brake disc on stock 35mm forks.
VT No.
Finish
23-1730
Black
23-1737
Chrome
23-1737
23-1730
Caliper Seal Kits contain seal and dust boot for year listed.
VT No.
OEM
Front
23-0606 44277-74
1974-77 FX
44278-74
Single Disc
23-0607 44151-77
1979-83 XL
44153-77
FX-FXE Dual Disc
23-0608 44133-72
1972-Early 80 FL-FLH
44127-72A
23-0609 44007-80L 1980-84 FLH
44133-72
23-0610 43945-79
1979-83 FLT
44947-79
VT No.
OEM
Rear
23-0608 44133-72
1973-Early 80 All FL-FX
44127-72A
14-0923 44127-72A O-Ring only for above
23-0609 44007-80
Late 1980-84 All FL-FX
44133-72
23-0610 43945-79
1980-85 FLT
43947-79
Dual Piston Caliper
Pistons Only, less seals, pistons are sold each.
VT No. OEM
Front
23-1722 44109-72A 1972-Early 80 FL-FLH
23-1725 44118-80 Late 1980-84 FL-FLH
23-1723 44275-74 1974-77 FX, 1974-76 XL
23-2278 44157-77 1978-82 FX
23-1721 43946-79 1980-82 FLT Front
1980-1987 FLT Rear
VT No. OEM
Rear
23-1724 44129-73 1973-Early 80 FX-FL
23-1725 44118-80 Late 1980-84 FX-FL
23-1721* 43946-79 1980-86 FLT
*Note: 1980-85 FLT have Dual Piston Caliper.
Caliper Piston and Seal
23-2278
23-0608
23-0609
