679
CLASSIC
Starter Related Hardware.
VT No.
OEM
Item
43-9165* Kit 1979-84
A, B, C, D, E, G, H, I, K, L, M
17-0240* Kit 1985-88
As Above
12-0317
9062
A Housing Needle Bearing
12-0318
9063
B Cover Needle Bearing
12-0934
11039
C Starter Motor Retaining Collar
17-0088
11041
D Starter Shaft Spacer
32-0638
31443-65A
E Bendix Drive
17-1508
31485-65
F Gear, 1980-85
17-0965
Steel
G Shift Lever, Starter FLT-FXR
17-0081
31493-67
H Nut for Shaft
17-9987
31495-79
I
Pivot Pin FLT-FXR
17-9988
31497-79
J Housing, 1980 FLT
17-9989
31497-81
J Housing, 1981-Early 83
17-9990
31497-83
J Housing, 1983-85
17-9995
31572-86
J Housing, 1986-88
17-1504
31502-65
K Thrust Washer
17-1502
31503-65
L Shift Collar
17-9983
33120-79
M Starter Shaft, 1979-84 FLT-FXR
17-9984
33121-79
O Spacer, Shaft, FLT-FXR
17-9985
31311-80
O Spacer FXST
*Note: Order appropriate housing to complete assembly.
Starter Shafts and Spacers.
VT No. OEM
Fits
17-0085 31482-70 1970-84 Big Twin
17-0019 31310-80A 1982-86 Big Twin
with rear belt drive
17-9983 33120-79 1980-85 FLT-FXR
17-0084 31530-65A 1965-84 Big Twin, Nut/Spacer
17-0085
Starter Shaft Housings are available as kits that include bear-
ing and mounting bolts or as
housings only.
Housing VT No. OEM
Starter Model
Only Kit
32-0990 43-9120 31465-65 Prestolite 1965-Early 79 FLH,
1971-72 FX
12-1147 —
Studs
As Above
32-0991 43-9121 31572-73 Hitachi
1973-Early79 FXE
32-0992 43-9122 31572-79 Hitachi
Late 1979-84 FXE,
1980-83 FXWG
32-0993 43-9123 31465-79 Prestolite Late 1979-82 FLH
1965-88 Housings
Starter Drive features high strength five roller clutch,
stainless steel springs, hardened ramped clutch receiv-
ers, premium bronze bushing and factory pre-lubing.
1965-88 Big Twin. Replaces 31443-65A.
VT No.
Brand
32-0638 Accel Heavy
32-0639 Volt Tech
32-2506 Volt Tech Heavy Duty
32-1097 Drive Kit
17-0238
Starter Shaft Assemblies include shaft, drive nut, collar, bearing
and thrust washer. Drive not included. Order starter drive sepa-
rately.
VT No.
Year
Model
17-0237 1965-69 FL
17-0238 1970-84 FLH
1973-84 FXE
17-0239 1980-84 FXB
1982-84 FLH
17-0240* 1985-88 FLT-FXR *Note: 5 Roller Starter Drive
*Note: Order appropriate housing to complete assembly
17-0241 1984-85 FXST
17-0242 1986-88 FXST
Starter Housing and Hardware Kits include housing, shaft, gear, arm,
pin, starter drive and related mechanical hardware only. Note: Starter and
electric components not included.
VT No.
Model
Type
43-9151 1970-84 Big Twin
Prestolite
43-9152 1970-84 Big Twin
Hitachi
43-9153 1980-84 FXSB
Hitachi
1982-84 FLH
Starter Housing Kits
43-9151 Shown
1979-84 FLT-FXR
43-9165
FLT Starter Housing. Order
bearing separately.
VT No.
Year
17-9990 L1983-85
17-9995 1986-88
17-9988 1980 only
17-9989 1981-E83
12-0317 Bearing
17-9990
17-9988
17-9995
17-9990
17-1508
17-0084
32-0993
32-0990
32-0991
32-0992
43-9120
17-0240
17-0965
17-0240
