1970-up Wiring Kits feature plastic wire in original factory
color codes, with all terminals applied, in vinyl loom. Complete
“Builders kits” include handlebar, taillight, coil and regulator
wires, denoted by an *. All other harnesses are main harness
only. Handlebar and taillight must be purchased separately for
these kits. Main harness include the main turn signal wires.
1970-up PVC Covered Wires
FL-FLH
VT No.
OEM
Application
32-0714* 70320-70
1970-72 FLH
32-0715* 70320-73A
1973-77 FLH
32-7569* 70320-78
1978-79 FLH
32-7568* 70320-80
1980-84 FLH
FX-FXE
32-7551* 70326-73A
1973-74 FXE
32-7584* 70326-75
1975-77 FXE
32-9066
70353-78
1978-79 FXS
32-9074
70343-78
1978-79 FXE
32-8014
70214-80A
1980-85 FXWG
32-8091
69543-80
1980-84 FXS-FXB
32-1118
69545-82A
1982-Early 84 FXR-FXRS-FXRT
32-0715
Early Twins Wiring Harness Kits are complete and feature
cotton braided wire and asphalt loom.
VT No. OEM
Application
32-7581 —
1916-28 JD Electric Model
32-0700 4735-30
1930-36 VL-RL
32-0701 4735-36
1936-37 WL-UL and FL
32-0703 4735-38A
1938-46 WL-UL-G and FL
32-7555 4736-42M 1942-45 Army 45
32-0704 70320-47
1947 WL-UL-G and FL
32-0705 70320-48
1948-57 UL-EL-FL-FLH & WL
32-0706 7032-58
1958-64 FL-FLH
32-0707 70321-65
1965-69 FLH
32-7555
32-0705
Wiring Harness Kits
PVC Covered Taillight Wires fit 1970-up.
32-9309
1970-72 FL, 1971-72 FX,
1973-77 FL
32-9310
1973-77 FX-FXE
32-9311
1978-84 FL
32-9313
1978-84 FX-FXE
Note: Order the appropriate factory service manual to
facilitate wire harness installation.
Generator Models
VT No. Type
Year/Model
Generator
39-0184 2-Light 1936-46 Big Twin
3 Brush
39-0534 2-Light 1936-37 Big Twin
39-0190 2-Light 1947 Big Twin
3 Brush
39-0189 2-Light 1948 Big Twin
3 Brush
39-0182 2-Light 1949-57 Big Twin
3 Brush
39-0183 2-Light 1958 Big Twin Neutral
2 Brush
39-0181 2-Light 1959-61 Big Twin, Neutral 2 Brush
39-0188 3-Light 1962-64 Big Twin
2 Brush
Replica Wiring Harness /Dash Base Assemblies include complete harness pre-wired to dash base, five or six post key switch,
terminal box, horn button, dimmer switch, headlamp connection, speedo lamp socket and front terminal board when required.
Switch and wiring are tested after final assembly.
Accessory Kits.
VT No.
OEM
Type
32-1078 70209-41 Ground Wire, BT
32-7549 —
1952-64 Turn Signal Kit, Cotton
32-0524 —
1958-84 Turn Signal Kit, PVC
32-9205 —
1965-84 Big Twin
Small Starter Wire Set, PVC
32-0163 70165-58 Battery Box to Ground 1965-69 Big Twin
32-0323 70018-77 Relay to Solenoid Wire
32-0158 70169-70 Relay to Ground Wire
39-0183
39-0187
39-0186
Big Twin Electric Start Models
VT No. Type
Year/Model Generator
39-0185 3-Light 1965-67
2 Brush
39-0186 5-Light 1968-69
2 Brush
39-0196 5-Light 1970-71
39-0197 5-Light 1972 only
39-0187 5-Light 1973-77
39-0198 5-Light 1978-79
39-0199 5-Light 1980-84
39-0185
39-0199
39-0198
39-0188
39-0197
39-0190
39-0182
Wiring Harness Kits with Dash Base
39-9309
32-7551
32-7584
32-0714
39-0184
