696
6 Volt Universal Battery. Dry charged.
Measures 4⁵⁄₈” x 3¹⁄₈” x 6⁵⁄₁₆”.
VT No. 53-0524
6 Volt 18 Amp Sealed Maintenance Free Battery
measures 6¹⁄₂” tall and 3¹⁄₂” wide. Battery has spade
type top terminals can be used as H2 replacement but
will require shimming by installer.
6 Volt
Item
53-0570 Battery
49-1555 Box for Wrap Around Tanks
H-2 Battery replaces 66006-29F for 1936-64 Big Twin 1929-63
45.
Dry charged.
VT No.
Item
53-0795
V-Twin Black does not include vent tube,
vents through caps
53-0566
Top Plug Set
32-1808
Ground Wire
53-0795
53-0795 Top
53-0570
Replica 6 Volt Batteries feature black cases and correct size
terminals as original. Batteries are stock style without vent.
Dry
charged.
VT No. OEM
Fits
53-0520 66001-47 H-3 measures 4³⁄₁₆” x 3⁹⁄₁₆” x 5³⁄₈”
K and XL
53-0529 4303-26 1930-36 VL, H-1, 3⁷⁄₈” W x 6⁵⁄₈” L x 6¹⁄₂” H
Note: Do not over fill, fill to cover top of plates only as per instructions provided. This
battery vents through the caps.There is No Warranty on Leakage due to over filling.
53-0520
53-0529
12 Volt Battery fits 1973-91 FXE-FXR, 1984-90 FXST-FXWG
measures 7” x 4” x 6¹⁄₄”.
Dry charged.
VT No OEM
Item
53-0502 65991-75C
12N16-4B
V-Twin, 16 amp
53-0517
Yuasa,
Yumicron
53-0518
Yuasa CX 19 amp
1970-79 Kickstarter models. Dry charged.
53-0504
12N7-4A
Custom application for Panhead-Knucklehead. Dry charged.
4¹⁄₁₆” x 3¹⁹⁄₃₂” x 4¹⁄₂”. Fits in 42-9916 Box
53-0505
12N5.5A-3B
V-Twin
53-0527
12N5.5A-3B
Yuasa
12 Volt Battery
Big Boar Batteries have high cold cranking amps, and a
replacement warranty. The 53-0700 battery is a totally sealed,
maintenance free battery. Measuring 6⁷⁄₈ long x 6¹⁄₁₆ high x 3⁵⁄₁₆
wide, and has been tested and proven on big inch and high
compression engines. It has true 350 cold cranking amps.
VT No. OEM
AMP Fits
53-0700* 65991-82 350 FX 73-86, FXR 82-94, Softail 94
53-0702
“Mini” 6” Length x 5¹⁄₈” T x 3¹⁄₄” W
*Note: For custom application that have limited space. Starts
larger engines but does not have a lot of reserve. Multi-
positional. Cold cranking 230.
53-0700
53-0702
Big Boar
Battery
Warranty and Adjustment Policy
This battery will be replaced without charge if found to be defective in materials or workmanship 6 months from date of over-the counter purchase. After 6 months but within 12 months of over-the
counter purchase, the battery will be replaced and the purchaser charged only for the period of ownership based on the regular price at the time of return prorated over the number of months of
warranty. This warranty is available through the dealer to the original retail customer and is not transferrable and is voided by the use of rejuvenators, improper electrolyte, neglect or abuse.
H-12 Battery fits electric start 1965-84 FLH, replaces 66006-65
and measures 8¹⁄₈” x 5¹⁄₄” x 6¹⁄₂”.
Dry charged.
VT No. Brand
53-0532 Champion/Super Crank
53-0579 Cap Set
Champion
53-0517
53-0518
53-0502
53-0505
53-0527
53-0579
All dry charged batteries do not include electrolyte. Electrolyte (battery acid) is avail-
able at Tractor Supply stores, nationwide.
6 Volt Battery
All dry charged batteries do not include electrolyte. Electrolyte (battery acid) is avail-
able at Tractor Supply stores, nationwide.
12 Volt Antigravity Battery. 480 cold crank-
ing amps.
VT No.53-0075
