731
CLASSIC
Cateye Dash
Cateye Dash Base
VT No. Fits
Type
39-0159 1939-46 Cateye Rebuild Kit
2714-36 Restoration Hardware Kit
2714-36T As Above
39-0156 1936-37 Skull
39-0455 1938
Skull
39-0145 1939-46 Replica Kit
39-0229 1939-46 V-Twin
39-0408 1939-46 Base
39-0127 1936-46 Custom
39-0129 1936-84 Custom
39-0128 1939-46 Wired
39-0184 1936-46 Replica Complete with harness
39-0408 1939-46 Bare Dash
39-0241 1939-46 Dash Assembly
39-0156
39-0128
39-0129
39-0127
39-0145
(A) Cateye Dash Lens Kit replaces 71340-39 and 71341-39. Sold in a set.
VT No. Finish
39-0113 Chrome
39-0206 Parkerized
39-0208 Zinc
(B) Dimmer Switch. Cateye dash mounting plate dimmer switch with knob.
Replaces 71600-39.
VT No Item
Year
Finish
39-0119 Complete Switch 1939-46 Chrome
39-0225 Complete Switch 1936-38 Replica
39-0230 Complete Switch 1939-46 Replica
2560-2
Switch Knob
1943-46
Chrome
2561-2
Switch Knob
1943-46
Parkerized
2562-2
Switch Knob
1939-43
Chrome
39-1529 Switch Handle
1936-38
Alloy, Replica
2610-1
Switch Handle 1937-38
Cadium
2609-4
1937-46 Contact Springs
39-0448 Knob Kit
1939-46
(C) Early Reset Knob. Original knurled type, clear stamped two and three, and
cateye dashes on early models.
VT No. 39-0336
(D) Panel Lamp Shields
VT No. 39-0359(E) Panel Side Plate. VT No. 39-0350
2810-13
Switch 1937-38
2811-13 Switch 1937-46
Replica 1939-46 Cateye Dash
Base Parts.
VT No.
Item
2714-36
Mount Kit
2714-36T
Mount Kit
33-2046 Bulbs
2862-2
Contact Spring, cad
2609-4
Contact Spring Kit
Dash Plate Mounting Kit contains all
hardware required to properly install the
dash plate & cover on all 1936-46 BT.
VT No. Item
7715-6
Stud Kit
39-0201 Switch/Stud Kit
39-0523 Lens Kit
39-0232 Lens Kit
39-0184
2561-2
2562-2
39-0201
39-0230
39-0225
39-0112
39-0898
39-0447
39-0360
39-0894
Cateye Dash Kit is complete as
illustrated. Packaged on 18” x 24”
board for point of purchase display.
Can be ordered with either plain
(39-0129) base, with sockets and
bulbs. Includes either 1:1 or 2:1
ratio speedometer and the correct
five post key switch with two keys.
Order VT No. 39-0129 “Plain Base”
dash kit when it is not desired to rewire harness for lighting
base. Order cable separately.
Can be mounted on 74 and
80 Big Twins 1936-84 models, 1936-73 45 models fitted with
1947-up style tanks.
VT No.
Type
39-0900 1:1 With Plain Base
39-0901 2:1 With Plain Base
39-0902 1 1 With Wired Base
39-0903 2:1 With Wired Base
39-0899
Without Speedometer with Plain Base
39-0903
Installed
2714-36
Pre-War 1939-41 Cateye Dash Panel V-Design
VT No. Finish
39-0863 Black
39-0894 Chrome V
28-0541 Rubber Trim
39-0831 Raw Oiled
39-0863
49-0834
2714-36T
Cateye Dash Cover fits 1939-46 Big Twin and 45 models.
Includes lenses and rubber trim.
VT No. Finish
39-0360 Raw
39-0522* Raw (Profile for 1942-46)
39-0446 Black
39-0898 Black
39-0447 Chrome
39-0112 Chrome
49-0834 Dash Mounted Choke Control
*Note: Dash Cover Only. Does not include lens set, trip knob
side plate or rubber trim.
