732
Light Sockets available with a steel
or plastic body. Bulbs are included.
VT No. Item
33-0129 1 wire, 3 pack
33-3065 1 wire, 3 pack
33-1983 2 wire, 3 pack, plastic
Note: Bulbs not included
33-2007 2 wire, 3 pack, steel
Socket has ground wire
33-0534 2 Wire, Insulated type, pair
33-0531 Speedometer socket
33-0136 12V Bulb
33-0244 6V Bulb
33-2007
Dash Mounting Plates available plain.
VT No.
Fits
Year
39-0138 2 and 3 1948-95
39-0207 All
1948-95
39-0944 Cast
1973-95
39-0138
39-0944
Wiring Harness/Dash Base Assembly
Replica Dash Bases feature correct shape and bulb sockets.
VT No.
Year
Type
39-0958 1948-58 2-Light
39-0963 1959-61
2-Light
39-0959 1962-67
3-Light
39-0960 1968-95
Cast
2713-42 1947-95
Insulators
Replica Wiring Harness /Dash Base Assemblies include
harness pre-wired to dash base, five or six post key switch,
terminal box, horn button, dimmer switch, headlamp connec-
tion, speedometer lamp socket and front terminal board when
required. Switch and wiring tested after final assembly.
VT No. Type
Year/Model
Generator
Generator Models
39-0834
1936-37 EL
39-0184 2-Light 1939-46 Big Twin
3 Brush
39-0190 2-Light 1947 Big Twin
3 Brush
39-0189 2-Light 1948 Big Twin
3 Brush
39-0182 2-Light 1949-57 Big Twin
3 Brush
39-0183 2-Light 1958 Big Twin Neutral
2 Brush
39-0181 2-Light 1959-61 Big Twin, Neutral 2 Brush
39-0188 3-Light 1962-64 Big Twin
2 Brush
32-1871
Harness
1948-69
Big Twin Electric Start Models
39-0185 3-Light 1965-67
2 Brush
39-0186 5-Light 1968-69
2 Brush
39-0196 5-Light 1970-71
ALT
39-0197 5-Light 1972 only
ALT
39-0187 5-Light 1973-77
ALT
39-0198 5-Light 1978-79
ALT
39-0199 5-Light 1980-84
ALT
Note: Order the appropriate factory service manual to
facilitate wire harness installation.
39-0963
39-0959
39-0958
39-0960
39-0182
39-0187
Dash Base Boot fits
1965-95 models.
VT No. 28-0412
VT No.
Item
39-0209 Kit
39-0210 Spacer, Front
39-0214 Spacer, Rear
28-0403 Rubber Strip
28-0562 Rubber Bushing
39-0209
39-0118
39-0422
Late Dash Base/Ignition Switch
Spacers for spacing dash base
and switch in relation to tanks,
packs of 10.
VT No. Size
Type
39-0420 .030
Dash
39-0421 .060
Dash
39-0422 .120
Dash
39-0118 .040
Switch
2713-42
Dash Rings and Plate
VT No. Item
39-0594 Mounting Ring
39-0596 Dash Plate
39-0994 Speedometer Ring
Dash Mount Hardware includes
bolts, spacers and hardware to
install 1948-98 type dash mount
bases on 1984-98 FXST-FLST
models with flat side tanks.
32-1871
39-0184
39-0594
39-0596
39-0994
