742
Oil Line Fittings for ³⁄₈” hose. Thread is
1
/
8
” NPT.
Chrome Zinc
OEM
Type
U/M
40-0566 40-0635 63533-41 Straight, Replica
5
2070-1
As Above
Each
40-0521 40-0637 Barbed
Straight
5
40-0519
26496-75B 90 degree angle
5
Chrome Male Fittings for gas and oil measured in NPT
thread and inner diameter of line.
A-Straight B-90°
Size
40-0525
40-0532
¹⁄₈
” NPT - ⁵⁄₁₆” Hose
40-0526
40-0529
¹⁄₈
” NPT - ¹⁄₄” Hose
40-0566
40-0519
¹⁄₈
” NPT - ³⁄₈” Hose
40-0527
40-0530
¹⁄₄
” NPT - ⁵⁄₁₆” Hose
Chrome Male Female Fittings.
VT No. #
Type/Size
40-9990 C 45°
¹⁄₈
” NPT - ¹⁄₈” NPT, Street Elbow
12-1416 D 90°
¹⁄₈
” NPT - ¹⁄₈ NPT
12-1419 E Straight
¹⁄₈
” NPT - ¹⁄₈” NPT
Male Plugs.
VT No.
#
Size
23-0611 F ¹⁄₈” NPT, Chrome
40-0531 F ¹⁄₄” NPT, Chrome
37-8777 G ¹⁄₈” NPT Hex Socket Plug, Plain
40-0609 H ¹⁄₄” to ¹⁄₈”
NPT
Oil Fittings for Big Twin.
VT No. # OEM
Item
40-0566 F 63533-41 Straight
12-1412 A 63533-65
Oiler Return
40-9982 B 63541-70
Oiler T, Rear Chain
40-0579 E Chrome
As Above
40-0552 F 26314-99
Straight 1999-up
17-0519 E 62375-57
Elbow
40-0553 E 63554-90
Elbow
Oil Vent “T” fits 71-84 Big Twin.
VT No. 40-0559
40-0566
40-0519
40-0521
Oil Line Fitting
Magnetic Drain Plugs prevent metal particles from circulating
through engine and transmission cases and oil tank.
VT No. OEM
Size
Use
37-0096 707
¹⁄₂
” - 13 74 and XL Transmission
37-0097 700
³⁄₈
” - 24 Big Twin Case Plug 74 & 80
37-0095 60348-65A ¹⁄₂” - 20 74 & 80 Inner Primary
37-0098 720, 706A ⁵⁄₈” - 18 Oil Tank and Timing Hole
37-0099 739A
¹⁄₈
” - 27 NPT 1990-up BT Trans
37-8961 718
¹⁄₄
” - 18 NPT Chain Cover
Banjo Bolts and Washers.
VT No. OEM
Item
40-0518 63678-36
Vent Line Banjo Bolt
40-0670 63577-36
Vent Banjo Fitting
14-0154 6440
Washer, Vent Lines, 10 pack
40-0156 3520-36A Bolt, Feed and Return, each
40-0157 3570-36B Washer, Feed, 10 pack
Oil Tank Drain Plug in stock chrome, cadmium
or parkerized finish.
VT No. Finish
Type
8114-1 Chrome
Stock
8115-1 Cadmium
Stock
9404-1 Cadmium
Oversize
9304-1 Chrome
Oversize
9714-1 Parkerized
Oversize
9502-1 Chrome 1939-51
Stock
9504-1 Parkerized as above, ⁷⁄₈” Hex Stock
9503-1 As above cadmium
Stock
37-9067 Washer
25 pack
Cadmium Oil Nipple Cap replaces 3583-15 to cap oil
fitting during storage. Pack of 6.
VT No. 9808-6
Drain Plug Washer for use on 1952-up brass
crush-seal factory type. Replaces 62702-52.
(10 pack).
VT No. 15-0194
Nipple Nuts and Tube Ends will attach to tapered tank
63533-15 type fittings and will accept braid or rubber hose.
Available straight, 90° or 45°, with chrome finish.
VT No. # Item
40-9975
Nut, 3 pack
40-9992 A Straight Tube, with nut
40-9993 B 90° Elbow, with nut
40-9994 C 45° Elbow, with nut
40-0514 D Fittings
37-0095
40-0514
40-0609 H
B
C
40-9975
A
Oil Line and Vent Line Fittings replace
type used on 1936-64 Big Twins. For braid-
ed stainless steel or stock rigid steel oil
lines, three pieces.
VT No.
Type
7612-3 Cadmium
7148-3 Chrome
40-0514 Chrome
40-0297 Zinc
7612-3
40-0635
40-0637
Rear Chain Oiler Fitting fits 1941-
69 FL, zinc. Fitting is positioned
between the oil pressure gauge and
oil pump fitting.
VT No. 12-1280
Cadmium
Chrome
