761
CLASSIC
52-0945
Inside Bead
Width 2.20”
Order spokes by hub style as shown.
45-0409
Spoke
Wheel Rim
(B) 45” Solo
Front Hub 1938-
52. Sets include
20 short and 20
long spokes.
(C) 1952-63
K and XL ¹⁄₂
Drum Front
Hub
(A) 1936-
up Big
Twin, Side
Valve,
OHV
Chrome Spoke and Rim Set includes chrome
rim with 40 chrome 6-8 gauge spoke and nipple
set. Fits 1936-up Big Twin, 16” x 3.0”.
VT No. 52-0300
52-0763
52-0208
52-1016
Steel Wheel Rims feature OEM style bead construction. Note:
Spoke nipple holes may require enlarging before assembly
with aftermarket spoke sets.
VT No. OEM
Fits
Finish
Size Model
52-0947 43004-35 F & R
Black
18”
Big Twin
52-0768 Powder F & R
Black
18”
Big Twin
52-1018 43005-35 F & R
Chrome
18”
Big Twin
52-1040 Black
F & R
Black
18”
VL
52-1016 Powder F & R
Black
19”
VL
52-0962 —
F & R
Chrome
19”
52-0963* —
F & R
Black
18”
52-0964* —
F & R
Chrome
18”
52-0025 —
F & R
Alloy 18”
52-0232
Black Powder
18” X 2.15”
52-0026 —
Alloy
19”
WR
52-0027 Alloy
F & R
18”
WR
52-1034 —
Black
19”
52-0969 —
F
Chrome
19”
1952-63
52-0965 43002-64 F
Chrome 19” 1964-72
52-0967 —
F
Black
16”
45 Solo
52-0966 —
F
Chrome
16”
45 Solo
52-0762 —
F
Black
18”
Indian
52-0433 Replica F & R
Chrome
16”
Police
52-0434 Replica F & R
Black
16”
Police
*Note: Features reverse roll and deep dish spoke area to fit
models with integral ¹⁄₂ brake drum.
Note: 45 Solo Replica Front Rims VT No. 52-0966, 52-0967,
and 52-0996 require OE style rim spokes.
Spokes for 1930-36 VL Front and Rear.
For OE Style Rim.
Chrome Nickel Size
45-0735 45-0818 18”
45-0736 45-0820 19”
45-0985 Hub, Nickel Plated
45-0710
45-0757
52-0785
52-0768
1936-up Big Twin, Side Valve, Overhead Valve (A)
VT No.
Finish
Size Rim
45-0710 Cadmium
16” Drop Center
45-0757 Zinc
16” Drop Center
45-0651 Stainless Steel
16” Drop Center
45-0409* Stainless Steel
16” Drop Center
49-0819 Zinc
16”
45-0720 Chrome
16” Drop Center
45-0621 Chrome, V-Twin
16” Drop Center
45-0743 Parkerized
18”
45-0744 Cadmium
18”
45-0652 Stainless Steel
18”
45-0748* Stainless Steel, V-Twin 18”
45-0763 Nickel
18”
45-0820 Zinc
18”
45-0721 Chrome
18”
45-0601 Chrome, V-Twin
18”
45-0653 Stainless Steel
19”
45-0602 Chrome V-Twin
19” Conventional
45-0160 Cadmium
Nipple Set
1938-53 45” Solo Front (B)
Finish
Size Rim
45-0664
1
Stainless
18” Conventional
45-0783 Stainless
18” OE
45-0697 Stainless
18” OE Style
45-0752* Stainless
16” Drop Center, OE Style
45-0877* Stainless Steel, Replica 16” Drop Center, OE Style
45-0922 Stainless
Nipple Set, 40 pcs, 1936-52
1952-63 XL-K Front (C)
VT No.
Finish
Size Rim
45-0708 Stainless
18” Conventional
Note 1: Cross One Pattern on Brake Drum Side
See page 471 for
Complete Rim Listings
.
Conventional Rims are flat style. 40 holes.
Chrome Black
Size
Width
52-0208 52-0785
18” 2.15”
52-0202 —
19”
1.85”
52-1057 52-1016
19” 2.15”
52-1043 52-1041
19” 2.50”
52-0748 52-1208
21” 2.15”
52-0203 52-0763
21”
1.85”
52-1291 —
23” 3.00”
WM Type Rim
WM1 = 1.6”
WM2 = 1.85”
WM3 = 2.15”
*Note:
Polished
Stainless
Steel Spokes.
45-0985
52-1208
