764
Deluxe Star Hub
Rebuild Kit fits
1936-66 inter-
changeable hubs,
includes inner
and outer stars.
screws, gaskets,
thrust washers,
outer bearing
sleeve, snap rings, cork retainer washer and standard rollers.
VT No. 44-0414
1936-66 Internal Star Hub
Component Kit includes
internal rebuilding parts
to assemble a bare hub.
Everything pictured except
hub. Includes standard roll-
ers. Fits all interchangeable
wheels 1936-66 if oversize
rollers are needed order from our 9220 series in .0002 to .002.
VT No. Years
Finish
44-0413 1955-66 Chrome
44-0431 1936-54 Parkerized
Hub Thrust Plate Kit includes inner star, grease fitting, and
outer chrome or parkerized star. Replaces 43569-55.
VT No. Finish
Fitting
44-0535 Chrome
With fitting
44-0559 Parkerized With fitting
44-0604 Parkerized Without fitting
44-0924
Gasket Hardware
44-0604
44-0535
44-0414
44-0413
Star Hub Components. Available in packs for 1936-66 hubs. See complete
kits on this page for rebuilding.
Index
Application
VT No.
OEM
1 & 2
Thrust Bearing Cover
Screws & Lock washers
8200-10 Chrome
8201-10 Cadmium
9670-10 Parkerized
3 & 5
Hub Thrust Plate Kit
44-0535 43569-55
3
Star Outer Cover, Chrome
44-0527 43566-35A
3
As above, chrome
44-0465 43566-35
Chrome Star
44-0458
Without hole
4
Small Cork
15-0350 43570-35
4, 6 & 21
Gasket and Seal Kit
15-0630
4, 6 & 21
As Above GB
15-0637
6
Star Gasket
15-0173
43576-35
6
Star Gasket
15-1054 James
7
Thrust Bearing
Adjustment Shims (10)
12-0708 43560-35
.002 Shim
12-0720
7
.015 Shim
12-9917
(10pc)
8 & 10
Thrust Washer (2)
44-0524 43563-35
9
Thrust Bearing Sleeve
44-0530 43556-35
11 & 18
Bearing Roller Set, 26 required
Std. Size
10-0319 9220
.0002
10-0320 9221
.0003
10-0339
.0004
10-0321 9222
.0006
10-0322 9223
.0008
10-0323 9224
.001
10-0324 9225
.002
10-0325
12
Roller Retainer, Small
44-0531 24721-30
13
Roller Retainer Thrust
Washer, 1 used, each
44-0523 43552-39
14*
Wheel Hub Chrome
45-0330 43540-36
Wheel Hub Black
45-0323
Assembly
15
Thrust Collar (for aftermarket hub)
44-0534 43561-39
16
Inner Sleeve 1939-66
44-0309 43549-36
17
Roller Retainer, Large
44-0532 43578-35
17
Roller Retainer Washer
19
1 used, 10 pack
44-0522 43558-39
20 & 23
Lock Ring, 2 used
10 pack
12-0921 43554-35
21
Large Cork
15-0631 43571-35
21
Large Cork, James
15-0231 43571-35
22
Retainer, Cork Washer
1 used
44-0521 43564-35
Grease Fitting 10 pack
44-0533 9851
Note: 14, Hub is assembled with all internal parts.
Replica Star Hubs include all internal parts, completely
assembled, for front and rear.
VT No. OEM
Year
Finish
45-0330 43540-36 1941-66
Chrome
45-0323 43540-36 1941-66
Black
45-0789 3958-36
1936-40
Black
45-0806* Timken
1936-66
Chrome
45-0807* Timken
1936-66
Black
*Note: Hub has 3/4" Timken type bearings and requires the
installation to fabricate correct axle, axle sleeve and spacer.
45-0323
45-0330
45-0789
Internal Hub Parts for 1967-72
interchangeable hubs FL-FLH models.
VT No. # OEM
Item
44-0392 A 41196-55 Seal Spacer
14-0131 B 41210-55 Seal 5 pack
45-0673 C 43540-67C Chrome Hub, Complete
45-0758 C 43540-67 Black Hub, Bare
44-0526 D 43542-67 Locknut (Left Hand)
44-0310 E 43549-67 Inner Spacer
44-0389 E 43549-67 1967-72 Inner Spacer
12-0331 F 43577-67 Bearing, each
44-0505 G 43592-70 Cover, Chrome
1967-72 Lock Nut and Seal Kit includes A, B and D.
VT No 44-0408
44-0408
Internal Bearing and Hardware Kit
for 1967-72 front and rear hubs. All
parts necessary to build or rebuild a
bare hub. Includes three bearings,
tube spacer, seal, seal sleeve and
hub lock (Left Hand Thread).
VT No. 44-0410
Star Hub Rebuild
1967-72 Hub
V-Twin replicated the “Star” Hub in 1980 with over 11, 000 being produced.
All internals interchangeable with original and replaceable with components
from our list.
45-0673
45-0806
45-0807
