778
Spring Fork Legs
Front Springer Fork Leg.
Black Chrome
49-0616 —
BT Spring Fork Leg
49-0408 49-0409 Spring Fork w/Rods, BT
49-0332 49-0343 45” Front Leg
49-0421* —
Stud Hole 45”/74” Adapters
7707-4
—
Spring Rods, pair
49-0337 — 45” Servi-Car R. Leg Inline
*Note: Allows installation of Big Twin Rockers on
45” fork.
49-0408
Lug Bolt Kit includes 5 lug bolts and “T” wrench.
VT No. Lugs
49-0830 Parkerized
23-1207 Chrome
49-0830
23-1207
Springer Brake Kit. Early style with
finned brake drum.
VT No.
22-0859 1936-39 (thin pressed drum)
22-0740 1938-40
Wheel Cover Set for glide fork applications on a 16” star hub
wheels with brake drum.
VT No. Fits
49-0299 1949-66 FL
Front
49-0291 1941-48 FL
49-0342
Inline Rear Fork Legs fit 1940-57 45”
Solo
Black Chrome
49-0388 49-0342
Brake Tab fits 1936-57 Spring Fork. Must
be welded on.
VT No. 49-2655
Spring Fork Front Brake Anchor Stud Kit includes
raw steel stud and parkerized adjuster screw. Brake
cable anchor stud for front backing plate was used
until 1940 on Knucklehead VL, UL, RL, and WL 45
”.
You can also use this stud to make a 1941 and up
backing plate into an early style backing plate. Must
be peened over or welded into place after installation.
VT No. 49-1742
Spring Components.
VT No. Item
49-1312 Fender Mount Tab
49-1172 Sleeve Set
49-0029 Front Tubes, Raw
49-0059 1" Stem
49-0374 ⁷⁄₈" Stem for 45"
49-1312
49-1172
49-0029
Wheel Lug Bolts for brake drums. Use tap 16-0807 for ³⁄₈ — 20.
Black Chrome OEM
Years Fits
37-8675 23-0440 43530-35A 1936-72 ³⁄₈ — 20
37-8691 —
43530-35A 1936-72 ³⁄₈ — 20
—
37-8919 43531-35 Oversize
⁷
⁄₁₆
— 20
49-0457 — 43531-35 1936-37
³⁄₈
— 20
23-0090 —
43631-35 1936 ³⁄₈ — 20
37-8675
23-0440
37-8691
49-0457
23-0090
37-8919
22-0740
Front Stand Mounting Kit
Parkerized reproduction of all items needed to
mount the front stand 1941-1942 G, and 1942-
1943 WLC.
VT No. 3086-12
Spring Fork
Black Brake Control Kit
features a pressed steel
brake drum, backing plate
with early adjuster, and
thin brake stay bar which
is exact for 1936-37 UL
& EL. Restoration quality
throughout!
VT No.
22-0452
Fits VL Spring Fork Assembly
49-1868 Black, Rear
7/8 to 1" Neck
Conversion Kit
includes cups and
tapered bearings for
1" fork to fit early
Sportsters and 45"
frames.
VT No. 24-1324
