791
CLASSIC
Spring Fork Brake
1941-64 Replica Brake Clutch Handle features accurate-
ly formed clamp and cadmium plated hardware. Replaces
45002-41.
VT No. Item
26-0541 Lever Kit
26-2143 Lever Assembly, Forged
26-0950 Lever Assembly, ⁵⁄₁₆” O.D.
26-0948 Front Parking Lever, Assembly
26-0946 Lever with ratchet plate
26-0947 Hardware Kit
13-0845 Spring
26-0821 Handlebar Lever Mount
26-0950 Lever Assembly, Polish, 1941-48
26-0951 Lever Assembly, Chrome, 1941-48
26-0953 Lever Assembly, Polished, 1949-64, brake
26-0954 Lever Assembly, Chrome, 1949-64, brake
26-0957 Lever Assembly, Polished, 1941-43, brake
37-1423 10-24 x 3/4 Fillister Screw, Cadmium 10 pk
37-1432 10-24 x 3/8 Hex Nut, Cadmium10 pk
Front Brake Cable Adjuster. One or two locknuts included
depending on application.
VT No. Year/Model
Finish
9740-2 1928-40 All
Chrome
8938-2 1928-40 All
Cadmium
9683-2 1928-40 All
Parkerized
9683-2T 1928-40 All
Parkerized
9739-2 1941-48 BT, 1941-57 Servi-car
Chrome
8624-2 1941-48 BT, 1941-57 Servi-car
Cadmium
9630-2 1941-48 BT, 1941-57 Servi-car
Parkerized
Brake Cable Cadmium Plated Brass Coupling and
Oiler includes the dust cover 4142-30. 1930-38.
VT No. 9004-2
36-0414
49-0422
Replica Lever Assemblies include slotted lever bushing as
original with small hole for brake or clutch.
VT No. # OEM
Finish
26-2127 A 45002-41
Chrome Complete
26-2126 A 45002-41
Polished Complete
26-0583* A Parkerized *Note: Bushing is not included.
26-2258 Polished
26-2174 45017-41 Parkerized
26-0948 —
Front Hand Parking
26-0510 B Ball End
Polished, Lever Only
26-0581 B Ball End
Polished, Stainless
Ball End Stainless Style Assembly.
26-0522 Ball End
⁵⁄₁₆
” Complete
26-0152 —
Polished, Screw In Type
26-0779 3/8” Hole
Polished
26-2192 —
Chrome Stock Lever Only
26-0542 —
Lever Clamp Strap
8819-4 45031-41
1941-64 Pin and Nut, Cadmium
26-0506 45033-49
1949-64 Lever Bushing with cotter
26-0522
26-0779
26-0152
26-0945
49-0894
26-2134
A
Ball End
26-0583
9630-2
9683-2T
26-0541
26-0947
Replica Brake Lever is an authentic reproduction, complete
as pictured for 1928-40 Spring Fork models.
VT No. OEM
Item
26-2134 Chrome
Complete Assembly
26-0945 Parkerized Complete, Assembly
26-0958
Chrome/Parkerized
37-8775 4154-28
Screw Set
49-0975 Parkerized Screw Set
26-2150 4150-28
Handle only
26-2151 4153-28
Lower Clamp
49-0422 45085-30A Cable Assembly, Replica
36-0453 Kit, Parkerized Handle and Fork Cable
36-2580 4143-30C
Cable Housing, Black Cotton
36-2578 ––
Cable Housing, Nickel Only
36-2567 ––
Inner
49-1523 ––
Pivot Screw
26-0949 Kit
Screw and Clamp
49-0975 Kit
Parkerized Screws
2958-4 Kit
Hand Brake Screw Kit
1941-48 Big Twin Spring Fork Cable and Handle Kit includes
replica style cable with oiler fitting and end ferrules, polished or
chrome handle and clamps to attach cable to bars and fork leg.
VT No. Type
Year
36-0414 Polished 1941-48
36-0775 Replica 1941-48
36-0418 Chrome 1941-48
36-0775 Replica 1941-48
49-0894 Chrome 1936-48
Replica Brake Cable
Assembly for 1930-57
Spring Fork, Big Twin and
45”. Includes housing with
end ferrules, oil cup kit and
inner cable. Replaces 45085-
30. Order clamps separately.
VT No. OEM
Item/Fits
Year
49-0432 45085-30
Cable Housing only, 45”
1930-40
49-0422 45085-30A Cable Assembly,
1941-57
Big Twin and Servi-Car
36-2567 —
Inner Cable, All
49-0256 45103-39
Oiler Cup
37-9027 9968
Clamp to attach to fork, All
37-0752 1190
Screw for Above, Parkerized
37-0924 1190
As Above, Cadmium
37-8776 9980
Clamp to attach to bars, All
9740-2
8938-2
9739-2
8624-2
26-0948
26-0821
26-0581
B
