807
CLASSIC
45” Model Components
45” Clutch Hub Related Parts for 1941-73 Solo and Servi-Car.
VT No. OEM
Year Item
49-0933 36916-36 1936-73
Cable End, Zinc
18-8304 36916-36 1936-73
Cable End, Cadmium
49-0046 36916-36 1936-73
Cable End, Parkerized
49-0160 36975-41 1941-73
Cable Assembly Parkerized
13-0743 36882-47 1941-73
Servi-Car Clutch Cable Spring
49-0126 —
As above
Chrome
49-0148 37052-44 1944-73
Clutch Arm, wide
8920-3 Rebuild All models
Fulcrum with rivets
8904-6* 37076-41 1941-43 Solo
Pivot Arm Bolt Kit
1941-73 Servi-Car
Cadmium
9709-6* As Above Parkerized
2639-1 37867-41 1941-73 45”
Clutch Lever Grease Fitting
8410-8* 37077-44 1944-52 Solo
Pivot Arm Bolt Kit Chrome
8411-8* As Above 1944-52 Solo
Cadmium
8412-1 37287-41 1941-73
Throw Out Bearing Assembly
18-0126 37287-41 1941-73
Throw Out Bearing Assembly
18-0127 —
1933-40
Throw Out Bearing Assembly
14-0126 37335-41 1941-73
Pushrod Seal Kit
12-0541 37358-41 1941-73
Adjuster Screw
12-0871
As Above
Screw with 12-0514 nut
45” Clutch Related Parts for 1941-73 Solo and Servi-Car.
VT No. OEM
Item
12-0514 37361-41 1941-73 Adjuster Nut
12-0556 37460-41 Hub, nut
17-0925 37462-41 Lock Tab
17-1925 —
Lock Tab
17-1926 37625-33 1933-40 Lock Tab
9533-2 —
Hub Nut with Lock
49-0088 —
Clutch Hub Complete
49-0061 37551-41 Hub, without bearings
49-0045
Clutch Hub with rollers
18-3674 37568-41 Ball Retainer with balls
18-3700 —
Retainer Only
18-3675 37577-41 Bearing Plate
18-3127 37586-41 Short Stud Set
18-3678 37590-41 CH. Liner with rivets
18-3224 37695-41 Clutch Drum
18-3703 37695-64 Clutch Drum, electric
18-3225 37713-69 Ring Gear without rivets
18-3227 Rivets, may be shortened for use on early drums.
Chain wheel must be riveted to clutch shell
18-3673 37873-41 Releasing Disc
18-1137 37952-41 Replica Clutch Set
37931-41 2 Full, +
¹⁄₂
plate
18-1123 As above Barnett Clutch Set
18-1128 37977-41 Steel Plate with rattlers
18-3672 38011-41 Pressure Plate
13-0139 38075-41 1941-73 All Clutch Springs
49-0983 Kit
Clutch Hub Bearing Kit
49-0474 Kit
Clutch Hub Nut
49-0419 34873-41 Sprocket Cover 1941-43 WL
49-0503 34873-41 Sprocket Cover 1941-43 W Narrow
49-0416 34873-44 Sprocket Cover 1941-45 W
49-0427 34873-44 Sprocket Cover 1944-53 WL
*Note: Includes bushings, pivot bolts and locks.
Replica Clutch Kit for 1941-73 45’s is riveted to steel plate just like original.
Consists of two full plates and one ½ plate, also available bonded to alloy by
Barnett.
VT No.
Item
18-1137 Friction Set (3 piece)
18-1128 Steel Drive, each
18-1123 Barnett Friction Set
18-1737 Kit, Complete
18-0451 Friction Plate (2)
45” Clutch Arm
49-0491 1941-43
49-0148 1944-73
45” Pushrod Seal Kit includes all parts
pictured.
VT No. Item
14-0126 Complete Kit
13-0229 37347-42 Spring Only
45” Big Fixx Kit
includes long roll-
ers to replace ball
bearings and cage
on clutch hub.
VT No.
Item
18-0230
Kit
49-0855
Plate
45” Main Drive
Gear Seal
Installer replaces
12747-41.
VT No. 16-0960
18-1137
Clutch Hub Nut Tool installs and removes
nut. Fits 1941-73 45”, handle sold separately
16-0908.
VT No. 16-0823
18-3672
16-0960
16-0823
49-0088
18-1737
14-0126
49-0045
45 Clutch Arms.
VT No
Item
49-1725
Throw Out Kit
49-1722
Clutch Arm Kit (W)
49-0491
Narrow Clutch Release Arm
49-0295
Clutch Release Arm, 1941-1952 W
49-0148
Clutch Release Arm, 1944-52 WL
3063-2
Hand Clutch Adjusting Screw Kit
49-1294
Narrow Arm Kit
49-1295
Wide Arm Kit
49-1722
Throw Out Arm and
Bearing Kit.
VT No. 49-1725
49-0491
49-0148
49-1725
Servi Car Clutch Cable Components.
VT No
Item
Finish
49-1747
Cable Kit
49-1672
Cable 1958-73
Parkerized
49-0126
Cable
Chrome
49-1723
Cable End
Parkerized
1/4” x 24
13-0743
Cable Spring
49-1682
WR Clutch Parkerized Pedal Kit
49-1278
Chrome Clutch Pedal Kit
49-1272
Clutch Pedal Kit, w/o cable
49-1672
18-3703
49-0983
49-1747
49-1682
49-1678
49-0295
16-0908
16-0823
Replica 45
Transmission
Case, bare case. 3
speed.
VT No. 49-0172
49-0172
Transmission
Bottom Stud
Kit for side valve
models.
VT No. 9919-3
49-1294
49-1295
