1952-71 K and XL Fork Parts
1954-70 XL Fork Boots and Hardware Kit includes gaskets, felts, retainers, washers, vent
tubes and clamps.
VT No.
OEM
Item
28-1994  46001-54
A-Boot set, pair
37-9016  Hardware
Kit Without Boots
37-9017  46007-54A
B-Boot retainer upper, pair
24-0680  10006
C-Boot Clamp
15-0668  46009-54
D-Washer, boot retainer, 10 pack
31-9019  46010-54
E-Disc, boot retainer, pair
37-9020  46020-57
F-Boot vent, pair
15-0669  46021-57
G-Gasket, boot vent, 10 pack
Front Brake Parts fit 1952-72.
VT No.  #  OEM
Item
N/A
A 44148-64 Polished Backing Plate
24-0116  B 44156-64 Pivot Stud, 1964-72
24-0609  C 44307-52 Chrome Lever
36-2385  D 45060-54 Cable Assembly
8818-3  E  45159-50 Adjuster, zinc
8818-3T  E  45159-50 Adjuster, zinc
9741-2  E Chrome  As Above
37-8676  F  45174-64 Zinc Clevis
24-0095  G 45203-52 Chrome Front Brake Tube
24-0646    As  Above Cadmium
2041-7  H 45218-53
Parkerized Throttle Cable Bracket
13-0146  I  41835-69 Spring Set, Parkerized
23-0505  J  44432-54 1952-63 Linings
23-0450  J  O.S.
1952-63 Linings
23-0506  J  41848-64 1964-72 Linings
23-0525    41849-64 Shoe Set
23-0519  K 44264-64 Brake Cam, 1954-72
Fork Tube Spring Retainer and Pin Wrench Kit
includes 2 retainers for 1952-72 Sportster and pin
wrench for installation and removal of retainers.
VT No. 7700-3
K and XL
Early Fork
Cover Set is
constructed
of chrome
plated steel
and includes
all panels
pictured,
replacing
46298-52A, 46269-52 46292-52 and 46291-52. The
46298-52A top panel does not have a key switch
hole covers or provisions.
VT No. 24-0261
1952-72
Damper
Tube
Assembly
includes all
components for both sides on XL and FX forks. This
is a direct replacement for 1968-72 models, and may
be installed  on 1952-67 models by drilling the lower
leg center hole to ⁷⁄₁₆” to allow use of larger mount
screw. Order spring set if required.
VT No.
Item
24-0454  Internal Kit
24-0900  Fork Springs
12-0908  Lower Snap ring
15-0327  Tube Gasket
Chrome Top Fork Tube
Plug replaces 45756-59.
Sold each.
VT No. 7621-1
Cable Clamp is fitted to hand lever for
emergency or permanent use. Easy to
install .460” diameter, pair
VT No. 26-0509
Brake Cable Clamp cinches
cable to brake arm.
VT No. 26-0508
23-0525
1952-56 K Model Clutch
Cable with adjuster.
VT No.
 Item
36-0406
Cable Assembly
37-8460
Adjuster Only
Rubber Cable Oiler Boot
replaces 38690-55, for XL
1955-80. 5 pack.
VT No. 28-0401
Replica Clutch Adjuster Sleeve. Fits
1954-71, ⁷⁄₁₆” hole levers.
VT No.
Finish
37-8460 Zinc
2576-1 Cadmium
15-0669
37-9016
Wire Harness for 1952-58
K-Model. 6 Volt. Replaces 70320-
56.
VT No. 32-7552
Tool Box Wing Nuts are zinc plated,
replace 64500-52A, pair.
VT No. 37-6136
Tool Mount Kits are cadmium, replace
64500-52A, pair.
VT No. 2005-9
K Mufflers have 2³⁄₈” body diameter, 1³⁄₄” inlet.
VT No.  OEM
Fits
Type
30-0742  65231-52 1952-56 K-H  21¹⁄₂” Replica
31-0231  65279-52 1952-55 K
Body Clamp
31-0226  65519-52 1952-56 K-H  Header Clamp, pair
30-0742  Replica  1952-56 K-KH  21¹⁄₂”
30-0742
Speedometer Drive Units include
housing and gear as replacement,
for transmission drive. 11 Teeth for
1952-72.
VT No.
Item
8900-1T Drive
15-0216
Gasket
15-1071 Gasket
8900-1T
K Battery Top replaces 66375-52 on 1952-64
6-Volt models, in chrome finish.
VT No. 42-0732
42-0732
Clutch and Brake
Lever Assemblies
include cable pin.
Available chrome
or polished with ³⁄₈”
or ⁵⁄₁₆” hole sizes for cable entry. VT No. 26-2167 and
26-2168 accept front brake switch.
Chrome  Polished OEM
Hole  Fits
26-0520  26-0521  38604-65A  ⁷⁄₁₆”  1965-70 Clutch
26-0525  26-0526 45002-65  ⁵⁄₁₆”
1952-68 Brake




1952-67 Clutch
26-2167  26-2168 45002-69  ⁵⁄₁₆”
1969-72 Brake
36-2385
Slider Bushing set of 4, replaces 45818-52. Use on
1952-72 XLH-XLCH models with steel lower sliders.
VT No. 24-0145
Front Brake Cable. Replacement
core and casing for 1952-72
Sportster models. Replaces 45073-
51 60” long, must be cut to proper
length.
VT No.
Type
36-2385
Stock Type, V-Twin
36-2565
Stock Type, M & M
36-0501
Stock Type, Barnett
36-2489
Braided Steel
Black
Zinc
OEM
Length  Top Nut
36-2570  36-2577  67051-52A 46”
⁵⁄₈
” F
1952-67 XLCH Cast
Sprocket Cover fea-
tures early rib design,
includes worm and
hardware, replaces
34874-52A.
VT No.43-0133
Stock Sprocket Cover Screws.
for K-Model 1952-53.
VT No.
Finish
8889-2
Cadmium
1952-57 K-Model Primary Cover Screw Kit.
VT No.
Finish
9852-5 Chrome
9853-5 Cadmium
Transmission Drive Speedometer
Cables. All have female nuts at
transmission end and top nut as
noted. Fit 1952-56 K Trans Drive
models.
Stainless Steel 1-7/8" Muf-
fler End Clamp Set.
VT No. 31-1236
