852
Head Bolts and Hardware Kits for 1986-up XL Models for one
head.
VT No.
# OEM
Item
37-9370 —
Hardware Kit (Includes D, E and G)
2011-8
E 16478-85A Head Bolt Chrome, 8 pack
F 16480-85A Screw Set, Late 1985-91 Big Twin
2012-8
E 16478-85A Head Bolt Chrome, 8 pack
F 16480-92
Screw Set 1993-up XL
9507-8
G 16832-86A Colony Stud Evolution, 1986-up XL
37-9260 G As Above
Sifton
37-8935 H 16573-83
Insert, 8 pack
12-1187 I 16715-83
Exhaust Stud, 5 pack
14-0516 J 26432-76
O Ring, 10 pack
37-9075 D 16482-85
Washer Late1985-92, Zinc, 4 pack
2017-8
D As Above
Chrome, 8 pieces
37-9370
Components
for One Head
37-8141
Heads and Hardware
Head Bolts, Head Nut and Washer Kits are the highest quality
available. Machined from high strength steel and hardened to
original factory specifications to prevent stretching. All bolts fea-
ture rolled threads for superior strength and fit.
Cad Chrome Fits Type
8945-16 8944-16 1957-72 Hex
—
9747-16
As Above Allen
9212-16 9211-16
1973-85 12 point
—
9748-16
As Above Allen
Head Bolt Washer Kit fits 1957-85 Sportster models.
8170-10 8488-10
Head Bolt
9110-9 Installed
Chrome Dome Cap Kit
1986-03 Head Bolt and
Spark Plug Covers are
die cast and chrome
plated to cover entire
head bolt area and
spark plug base. Held
in place by rubber boots
on spark plug wires. Fits 883-1200 XL models.
VT No. 42-0741
Chrome 12 Point Head Bolt Set
includes 8 washers and 8 head
bolts for 1986-92 XL.
VT No. 37-9019
37-9131 Installed
8944-16
883 XL Model. Ironhead motor
model features 1:10 scale with
authentic 1957 Sportster 900cc
details! Fully pewter casted and
mounted on a wooden base for
display.
VT No. 48-0746
48-1351
48-1545
Belt Buckles.
VT No. Style
48-1351 XLH Ironhead
48-1512 XL Gas Tank
48-1473 XLH Ironhead Electric Start
48-1545 XL Points Cover
48-7787 XLCH Sportster
48-1522 Complete Set
48-1512
48-1473
Finned Head Bolt Bridge.
Bolts on! 2004-up XL.
Chrome Black Silver
42-1158 42-1157 42-1156
48-7787
42-1158
42-1157
42-1156
Headbolt Covers fit over 12 point headbolts on 1973-85
XL Sportster, 1986-up Evolution 883-1100-1200 Sportster.
Evolution styles include four pieces for left side only 1973-85
Sportster kits include eight covers.
VT No. Finish Style Year
9110-9 Chrome Acorn
1973-85
9111-9 Gold Acorn 1973-85
9112-9 Chrome Cap
1973-85
37-8799 Chrome Cylinder 1986-up
37-9399 Black Cylinder 1986-up
37-9131 Chrome Grooved Cylinder 1986-up
2024-4 Chrome Hex Dome
1986-up
2262-4 Chrome Spike
1986-up
42-1092 Brass Spike
1986-up
37-8799
37-9131
2262-4
42-1092
2024-4
