866
1st and Countershaft Drive Gear.
VT No. Andrews # OEM
Teeth Shaft
Fits
17-1122 17-1050 A 35277-52A 27 Main
1954-90
17-1053 —
Sifton
27 Main 1954-90
17-0168* —
B 35760-54
17 Counter 1954-72
17-1119 17-1060 C 35760-73
17 Counter 1973-83
17-9825 —
D 35760-84A 17 Counter 1984-90
—
17-8580 E 35695-58
27 Counter 1958-86
17-5621 17-5620 F 35695-87
26 Counter 1987-90
17-1143 —
E Sifton
27 Counter 1958-86
*Note: Includes speedometer drive gear.
Clutch Gears for Sportster, 17 tooth, includes bushing and
Torrington needle bearing.
Andrews VT No. # OEM
Fits
—
17-1140 A 37449-56 1956-66 XLH-XLCH
—
1967-69 XLCH
—
17-1141 B 37448-67 1967-70 XLH, 1970 XLCH
17-8710 17-1142 C 37448-71 1971-E79 XL’s
17-8711 17-9760 D 37448-79 L1979-E84 XL’s
—
17-9826 E 37448-84A L1984-86
17-4850 17-9146 F 37448-87 1987-90, 18T
2nd Gears
VT No. Andrews OEM
# Teeth Shaft
Fits
17-1126 17-8241 35750-58A C 20 Counter 1958-90
—
17-8242 35296-56A B 23 Main
1956-90
17-1123 Sifton
35296-56A
23 Main
1956-90
3rd Gears
VT No. Andrews OEM
# Teeth Shaft
Fits
—
17-8243 35709-54B D 23 Counter 1954-90
17-1124 Sifton
35709-54B D 23 Counter 1954-90
17-1120 17-8244 35305-56A A 20 Main
1956-90
4-Speed Gear Sets For Sportster are available as kits which
include: 1st gears, counter and main, 2 pieces; 2nd gears,
counter and main, 2 pieces; 3rd gears, counter and main, 2
pieces; 4th gears, counter and main, 2 pieces: the counter-
shaft, and mainshaft,
must be ordered separately.
1973-78
1979-84
Evolution 4 Speed Brand
“W” 1st, Stock 4th
—
17-7654
—
Andrews
“W” 1st, “C”, 4th
17-6012
—
—
Andrews
Stock 1st, Stock 4th
17-6013
17-7657
—
Andrews
—
17-0761
—
V-Twin
Stock 1st, “C” 4th
17-6014
17-7658
17-7659*
Andrews
*Note: Requires use of early countershaft 35613-58, VT No.
17-0328, 17-1151 or 17-8248
A
A
B
C
D
F
17-1122
17-1140
17-1142
17-9760
17-1141
17-1119
17-5621
17-9825
17-0168
B
C
E
F
D
A
B
C
D
17-9146
17-9826
Andrews “C” Ratio Gear Sets provide true
close ratio shifting for XL gear boxes.
VT No. Fits
17-8721 1979-Early 84 All XL
17-4850* Late 1984-90 All XL
17-5622* Late 1984-90 All XL (Sifton)
Andrews Wide Ratio 1st Gear Sets
changes 1st from 2.52 ratio to 2.68 for
more low end torque with 21T or 22T
trans sprocket. Fits 1973-85. Can also
be used on 1986-90 models if early type
countershaft is used.
VT No. 17-9856
17-5622
Needle Bearings feature full compliment roller design.
VT No. Torrington OEM
Type/Use
12-0461 12-0326
35690-54 Closed Transmission
12-0396 12-0327
35961-52 Open, Transmission
12-0327
4-Speed
XLH-XLCH Gears
17-4850 Set
17-6011
17-1123
*Note: From 1987-90 all XL models have “C” Ratio Main Drive
Gears as stock parts. Also fits late 1984 alternator 1000cc models.
Gear
Stock Ratio
“C” Ratio
1st
2.52
2.29
2nd
1.83
1.66
3rd
1.38
1.26
4th
1.00
1.00
E
