898
Dual Disc Front Disc Calipers includes body, piston, seals.
Dual type fits 1977-83 FX-FXWG with 10’ brake rotors. Order
mounting hardware separately.
VT No.
Side
Finish
Style
23-2221 Right
Black
A
23-1121 Right
Chrome
A
23-2238 Left
Black
A
23-1119 Right and Left
Black
A
23-1122 Right and Left
Black, ET
B
23-2220 Right and Left
Chrome, Daytona
B
23-0550 Right and Left
Chrome, ET
A
Dual Disc Caliper Hardware fits 1977-83.
VT No.
# OEM
Item
23-0509 A 44098-77
Pad Set (4)
23-9198 B 44141-77
Seat, brake hose
23-1731 C 44146-77
Bleeder Fitting
23-0607 D 44151-77
Seal, piston
44153-77
23-2278 E 44157-77 Piston
23-0523 F 44158-77
Plate, Outer
44161-77
Plate, Inner
23-1734 G 44162-77
Pin
24-0602 H 44173-77 Screw
44174-77
37-8970 I —
Chrome Insert, each
24-0603 J 46018-77
Mount Bushing Set
46019-77
23-0550
Chrome Lower Slider Set Only fits 1977-82 dual
disc 35mm forks.
VT No. 24-0541
2004-up XL Front Calipers feature 4 pistons design in chrome.
VT No. OEM
Finish
Side
Model
23-0851 44121-04 Silver
Left
XLH
23-0852 44121-04 Chrome 2004-06 Left
XLH
23-0008 44546-04 Chrome 2004-06 Right
XLH
23-0286 44121-07A Chrome 2007-up Left
XLH
23-0821 42879-07 Chrome 2007-09 Left
“48”
23-0273 42822-04 Piston with seal 2004-06
23-0274 43529-04 Seal Kit
2004-06
23-0285 42028-07 Piston & Seal Kit 2007-13
23-0292
Seal Kit
2007-13
23-0827 41300006 Piston & Seat Kit 2014-up
23-0294
Front Seal Kit
2014-up
23-0852
23-0008
24-0603
24-0602
1977-83 Chrome Dual Disc Caliper
and Rotor Set includes (2) chrome
calipers and (2) 10” drilled rotors.
VT No.
Item
Rotor
23-0250 Caliper Rotor Set
Zinc Steel
23-0258 Caliper Rotor Set
Polished Stainless Steel
23-0259 Caliper Rotor Set
Stainless Steel
8758-10 Bolt Set
23-0259
23-0523
23-2278
23-0008
installed
23-2220
A
B
1977-83 Dual Disc
23-1119
2004-up Front Caliper
00-03 Front Caliper
Front Chrome Disc Brake Caliper Mount Bolt
Kit fits 2000-up models.
V-Twin Colony Year
37-0816
2080-4
2000-07
2754-12
2008-up
Left Chrome Front Caliper Cover
includes chrome trim disc to conceal
mount hardware. Fits 2000-2003.
VT No. 42-0844
23-0554
23-0554
Pistons Only, less seals, pistons are sold each.
VT No. OEM
Front
23-2279 44020-83 1983-99 XL
23-0532 44313-00 2000-03 All Front Only
Caliper Seal Kits contain seal & dust
boot for year listed.
VT No.
OEM
Front
23-2275 44047-83
1984-99 XL
44022-83
23-0533 44315-00
2000-03 All
Front Only
Front Caliper are 4 piston type including all internal components.
23-0554 features smooth face. Fits 2000-03.
VT No.
OEM
Side
Finish
23-0554 44046-00
Left
Chrome
23-0529 44046-00
Left
Black
23-0580 44025-00 Right
Chrome
23-0581 Set
Right and Left Chrome
23-0821
