908
Attention!!
These fork tubes have been manufactured and tested for exact fit and applica-
tion per model. It can be difficult to identify the front end assemblies because
they may not always be original equipment. Before installing, compare old and
new tubes. Be sure the stock top plugs fit into the new fork tubes. To avoid
scratching the chrome, we suggest that the tubes be lightly rubbed with oil
before installing into fork legs. Be absolutely sure you have the right tubes
before you install them. No fork tubes can be accepted for return that are
scratched or damaged due to improper installation or handling.
39 mm Fork Tube Assembly includes internals with springs,
assembled for 1987-99. Tube length is 23
3
/
8
”.
VT No. 24-0107
Note: See Vintage section for 1952-72 components.
Fork Tube and Slider Assembly available in right and left
pairs, completely assembled. Units have hard chrome fork
tubes, and either polished or chrome lower sliders, with springs
and all internal components installed.
39mm
VT No. Disc
Fits
Slider
24-0590 Single
1994-99 XLH
Chrome
24-0984
2000-03 XL
Chrome
24-0384
2004-up XL
Chrome
35mm
VT No. Disc
Fits
Slider
24-0589 Dual
1977-84
Polished
35 and 39 mm
Fork Tube
and Slider
Assembly
24-0107
39mm Chrome Single Disc Lower Fork Sliders for XL’s.
VT No. Fits
24-0373 1988-99
24-0079 2000-07
24-0353 2008-up
2273-7 Bolt Set
24-0079
24-0373
Fork Tubes are precision machined with ground
finish for fit and quality. Available in chrome or
hard chrome as stock. Sold in pairs.
Chrome Fork Tube
24-0353
Fork Cover Sets fit the space between the triple trees and
cover the fork tube like the 1960’s styling.
Note: Will not fit “48”
models, required front fender removal 14” long.
1986-03 2004-up Finish
24-1316 24-1318 Black
24-1315 24-1317 Chrome
24-1318
24-1316
24-1317
24-1315
39mm
1988-08 XL models 883-1200, 39mm except Hugger
24-0020 23³⁄₈”, Hard Chrome
24-0437 23³⁄₈”, Chrome
24-0019 25³⁄₈”, Chrome
24-0439 27³⁄₈”, (+2”) Chrome
24-0442 29³⁄₈” (+4”) Chrome
2009-up All XL models except XL883L, XL1200L, XL 883N,
XL 1200N
24-0390 Stock Hard Chrome
24-0391 2” over stock
24-0392 4” over stock
24-0393 6” over stock
35mm
1975-83 XLH-XLCH-XLCR, 1983 XLX-XLS
24-0013 Stock 23¹⁄₄”, replaces 45407-75, Hard Chrome
24-0425 2” over stock, replaces 45644-77
24-0426 4” over stock
24-0427 6” over stock
24-0428 8” over stock
1979-82 XLS models, Showa Fork. 35mm.
24-0425 Stock 25¹⁄₄” replaces 45644-77
24-0426 2” over stock
24-0427 4” over stock
1973-74 XL, Kayaba Fork. 35mm.
24-0015 Stock 23¹⁄₂”, replaces 45977-73, Hard Chrome
24-0421 2” over stock
24-0422 4” over stock
1973-74 XL
24-1073 Stock 23¹⁄₂”
1984-E86 XL, except sport pkg. 35mm.
24-0016 Stock 23¹⁄₄”, replaces 45407-83, Hard Chrome
24-0430 2” over stock replaces 45392-83, Hard Chrome
L1986-87 XL, 35mm.
24-0434 Stock 23¹⁄₄” replaces 45407-86
33.4mm
1954-72 XL
24-0012 Stock 22³⁄₄” replaces 45953-71, Hard Chrome
