924
Shock Set
Shock Sets for Sportster
includes chrome springs.
VT No. OEM
Length Fits
54-0106* 54490-78 14.5”
1975-78 XLH-XLCH
54-0099 54568-79B 13”
L1979-81 XL-XLS
XLH-XLCH
54-0098 54568-82 12.5”
1982-87 XL-XLS-XLX
1988-90 XLH 883 Hugger
54-0503 54568-92 11.75” 1993-03 XLH 883 Hugger
54-0144 54568-04 13.38” 2004-08 XL 1200
*Note: Use 54-0403 stud kit for installation on 1952-74 models.
14” Replica Shock Sets for 1952-78 Sportster include bush-
ings with1/2” hole use with 54-0460 stud kit.
VT No. OEM
Type
54-0100 54504-73
Chrome Springs
54-0101 54500-56A Full Covered
54-0403 Mounting Kit for Above
54-0106
54-0098
Shock Absorbers for Lowering Sportster
VT No. OEM
Length Fits
54-0098 54568-82 A 12.50” 88-90 XL 883 Std Deluxe XL 1200
54-0503 54568-92 B 11.75” 91-03 XL 883 Std Deluxe XL 1200
54-0503 54568-92 A 11.75” 91 XL Hugger, Stock on
92-03 Hugger models
54-0516 54568-92 As Above, V-Twin
Note: (A) Lowers seat height 1” (B) Lowers seat height 2”.
54-0099
Warning: Installing a lowering kit or shorter shocks will decrease initial ground
clearance. The motorcycle will be lower to the ground and care should be taken
to avoid bottoming, especially over bumps or in turns.
Mount Studs not included with shock sets.
Shock Bushings.
VT No. Year
28-0220 1954-73
28-0231 1982-84
28-2140 1985-up
28-0220
28-0231
24-2140
54-0100
Shorter Length Shocks lower the seat height by distance as
noted. Shocks feature chrome-plated springs and body caps
with suspension preload.
VT No. Fits
Finish Lowers Length
54-0143 1991-2005 XL 883
Chrome 1”
11.75”
1991-2005 XL 1200
11.75”
1991-2005 XL 883DLX
11.75”
1992-2005 XL 883R
11.75”
54-0516 All XLS, 1991-03
Chrome 1”
11.75”
54-0671 2006-2010 883 XL
11.75”
2009-up 1200 XL
54-0934 As Above
Black
11.75”
54-0191 As Above
Chrome 2¹⁄₄” 10.50”
54-0192 As Above
Black 2¹⁄₄” 10.50”
54-0143
Installed
Lowered Shocks!
54-0516
54-0671
54-0191
Installed
54-0101
54-0143
54-0192
54-0934
