Rear Axle Kit
Rear Axle Nut and Washers fit 1952-79.
VT No. Item
Finish
U/M
44-0326 Nut with washer
Chrome
Kit
37-8127 Nyloc-Nut
10 pack
44-0317 41598-52, Sportster 1952-77 Zinc
Each
44-0500 As Above
Chrome
Each
Chrome Rear Axle Nut and Washer Kit
includes two extra thick washers, nut and lock
washers for 1973-up, on square swing arms.
VT No.
Brand
8715-4
Colony
44-0520
V-Twin
Chrome Rear Axle Nut Kit includes washer
and cotter pin for rear axles on 1989-up models,
replaces 7987, 511. ⁵⁄₈ x 18 thread nut
VT No. 37-9032
Chrome Rear Axle Spring Clip replaces 510
spring clip used on all 1991-up, 5 pack.
VT No. 2042-5
Chrome Rear Axle Spacer Kits include castle nut for axle and
adjuster collars
Stock Grooved Years
2040-4
— 2000-03
9997-3
9996-3 1986-99
2258-5
—
2004
2257-4
— 2005
—
2483-4 2006-07
2510-5
— 2008-up
9997-3
9996-3
2040-4
Rear Axle Kits include chrome axle, nuts, sleeves and spacers
for each application.
Kit Cpt Spacer Collar Axle only Nut Kit Model
44-0565 44-0324 44-0317 44-0217 44-0326 1952-78
—
— — 44-0089 44-0326 1977-78, zinc
44-0566 — — 44-0220 8715-4 1979-85
44-0643 9997-3 — 44-0220 9997-3 1986-99
44-0644 2040-4 — 44-0220 37-9032 2000-03
44-0126 2258-5 — 44-0127 2258-5 2004
44-0125 2257-4 — 44-0128 2257-4 2005-07
44-0801 2510-5T — 44-0248 —
2008-up
—
— — 44-0259 —
2008-up, zinc
44-0643
44-0644
44-0566
44-0565
Chrome Rear Axle Nut Kit is a
custom hardware kit with installation
instructions. Fits 1979-up.
VT No. Type
8606-6 Acorn
8607-6 Cap
Rear Pike Axle Nut Cover Set fits 1993-
2003.
VT No. 2261-2
2261-2
44-0326
Rear Axle Spacers for XL.
VT No. Year
Side
44-0324 1955-78 Left
44-0421 1982-85 Left (Pair)
44-0427 1986-99 Both
44-0422 1979-81 Left
44-0424 1979
Right
44-0810 2004-07
Right and Left
44-0421
44-0422
44-0424
44-0427
Chrome Axle Kits include pike or acorn nuts. Fit 1979-2004
models. ³⁄₄” diameter.
VT No.
Style
44-0664
Pike
44-0665 Acorn
Pike
Acorn
44-0324
DIY Universal Axle Spacer is construct-
ed of stainless steel 6” long with ³⁄₄” inner
diameter are 1¹⁄₈” outside diameter, to be
cut to length.
VT No. 44-0670
