MULTI FIT/CHOPPER
Footpeg Arm Mount Studs feature spline with
1
/
2
” threaded end, longer type is keyed (for FXR
models), overall length shown.
VT No.
Length
27-0046  2⁷⁄₈”
27-1648 2
3
⁄₈
Chrome Footpeg Mount Kits
include clamp set and 3.5”
extension bars to accept male
pegs.
VT No.  Size
27-0032
 1”
27-0033 1
1
/
8
27-0034 1¹⁄₄”
27-0654
Chrome Billet Engine Bar
Footpeg Mount
fits on 1¹⁄₄” engine
bars to accept male pegs.
VT No.
Item
27-0654
Mounts
27-0660
Kit with pegs
27-0660
Footpeg Mount
Mounting Stud Sets for footpegs are available in a ³⁄₈” or ¹⁄₂”
thread. Order shoulder bolts separately.
VT No.
#  Finish
Item
9965-4
A
  Cadmium Bolts
37-0012  A  Chrome
Bolts
27-0050  B Zinc    ³⁄₈” 1965-up FL-FX Stud
27-1604    Chrome
³⁄₈
” 1965-up FL-FX Stud
27-0049  B Zinc    ¹⁄₂” 1974-up FL-FX Stud
27-1605    Chrome
¹⁄₂
” 1974-up FL-FX Stud
Footpeg Mounting Yokes are available in ³⁄₈” and ¹⁄₂” mount-
ing sizes. Sold in pairs.
Chrome Black  Thread  Length
27-0051
27-0169
¹⁄₂
”
1”
27-1534
27-1540
³⁄₈
”
1”
27-1719*
¹⁄₂
” x 13
1”
*Note: With studs.
⁵⁄
” frame hole inner
diameter. *Note:
Unthreaded use with allen
cap bolt, threads into
mount on bike.
VT No.
Length
27-0062* 1⁷⁄₈”
27-3563* 2³⁄₄”
Chrome Footpeg Mounting Shoulder
Bolt & Nut Kit features shoulder bolts
and locknuts to mount driver and pas-
senger pegs.
VT No.  Type
Driver
8850-4  Female FXE
8851-4  Male
FXST
37-0020 Male
FXST
Chrome Footpeg Bars are chrome
⁵⁄₈
” square steel, ³⁄₈” thread, pair.
VT No.
Size  #
27-1559 5” A
27-1557 2” C
27-1558 4” D
27-1590 3” B
VT No.
Size (Inner Diameter)
27-0057  1”
27-0059   1¹⁄₄”
27-0051
27-1534
27-0050 B
Chrome Footpeg Mount Bars are 3¹⁄₂” long
and accept male mount pegs and mount with ¹⁄₂”
x 13 bolts.
VT No. 27-0030
27-0037
27-0062
27-3563
27-1719
Footpeg Mount Blocks fit
1996-up FLT models to use
with male peg sets.
VT No. 27-0623
C
B
D
A
27-0892
Installed
Order diamond adjustable pegs
separately 27-3549.
Bar Clamps fit 1¹⁄₄”
engine bars to mount
male peg sets. Peg kit
includes soft pegs.
VT No.   Item
27-0892
Clamp Set
27-0895 Peg Kit
27-0895
Three Piece Frame Bracket is
chrome plated super heavy-duty
clamps. The unique three piece
design eliminates spreading the
clamp to fit over frames and safe-
ty bars for quick easy installation
and a long-lasting custom appear-
ance. Mount hole size noted.
27-0066
Chrome Billet Footpeg Extension
Clamps
attach to 1¹⁄₄” engine bar and
accept male pegs.
VT No. 31-1254
Engine Bar 3 Piece Clamp Set with male
footpeg mounts. Footpeg mount mounts to
clamp with ¹⁄₂” bolts included.
VT No. 27-0072
27-0072
Footpeg Mount Kit allows male-type
pegs to be mounted to 1
1
/
4
” diameter
engine bar.
VT No. 27-0651
1/2”   3/8”
Black
Inner
Mount Hole  Mount Hole

Dia
27-0052
27-0039
27-0001 1”
27-0053
27-0038
27-0002 1¹⁄₈”
27-0054
27-0037
27-0003 1¹⁄₄”
27-0066


27-0004 1¹⁄₂”
Chrome  Black
Inner Diameter
27-0701
1”
27-0654  27-1788 1¹⁄₄”
27-0702
1¹⁄₂”
Chrome Steel Mount Clamp for 1”
or 1¹⁄₄” diameter tubes with ³⁄₈” mount
hole. Sold in pairs.
37-0012 A
