Headlamp for Sportster
Stock Chrome Replacement Headlamp with H-4 unit.
Chrome Black Year
Fits
33-0196 33-1418 1974-84 XL-FX
33-0197 33-1419 1954-73 XL-FX
Tail lamps/Headlamps listed are for show or decorative use only, and not D.O.T. approved.
5³⁄₄” Stock Headlamp fits FX-FXE-FXD-XL-includes 12 volt
sealed beam, late type replaces 67705-74, has rectangular hole
in shell for wiring, early type has two connections on back of
shell. Order rubber insert 28-2004 for the late type separately.
VT No. Finish
Year
33-0232 Chrome
1971-73
33-0233 Black
1954-73
33-0231 Chrome
1974-84
33-0230 Black
1974-84
28-2004 Rubber Boot
1974-83
28-0223 Rubber Ring
1954-83
33-0522 Chrome, Outer Rim Set 1963-up XL
*Note: Features halogen bulb and 2 holes in shell for wiring.
28-0223
33-0232
33-0230
33-0231
33-0231
Back
33-1419
33-0196
Back
33-0197
Back
33-1418
Headlamp Visor
Chrome Headlamp Mount Kit includes
nut, tapered spacer, lockwasher and
chrome cap plug.
VT No.
Year
37-8855 1954-88
37-9006 1989-up
Chrome Sunvisor shields
the LED’s on the headlamp
mounting bracket from the
sun.
VT No. 42-0321
Chrome Headlamp Visor Cover fits over existing head light
visor on 1971-up FX models. Available with or without cutaway
for oil and generator lights.
VT No.
Cutout
42-0306 With
42-0307 Without
42-0306
42-0307
Chrome Die Cast Headlamp Bracket for FX Narrow Glide
models.
VT No. OEM
Years
Type
42-0422 Plain
Without Light Holes
42-0423 67807-73 1971-73
Two Large Holes
42-0424 67809-75
1975-8
Two ¹⁄₂” Holes
42-0069 67805-86 1986-91
4-Light
42-0838 67805-92 1992-up
With Slot
42-0422
42-0424
42-0838
42-0423
42-0069
Chrome Headlamp Visor
Plug fits die cast headlamp
mounting visor center hole.
VT No.
Years
28-1500
1954-88
37-0538
1989-up
Chrome Headlamp Visor Mount Bolts for use on all XL-FX-
FXR 1959-up.
VT No.
Type
8717-4 Acorn
9783-4 Allen
Acorn
Allen
37-0538
Headlamp Bracket Extender fits
1971-up FX-XL-FXD.
VT No. 31-0143
