MULTI FIT/CHOPPER
Side Mount
Tail Lamp
Note: Side Mount Units available with bracket
to mount to shock bolt with ³⁄₈” or ¹⁄₂” thread on
1979-up models or with ⁵/₈” x 20” acorn nut to
axle on 1967-78 XL’s or Rigid applications.
Softail types fit 1986-up Softail models
.
Billet Noid Side Mount Units fit 1986-up Softail.
VT No. Style
33-0394 Vertical
33-0396 Curved
33-0395 Horizontal
33-0396
33-0395
33-0394
Billet Side Mount Lamp
features LED with ¹⁄₂”
mount hole, with ¹⁄₂” x 1”
spacer for shock or frame
mounting.
VT No. 33-1249
Chrome Billet Vertical Tail Lamp Assembly to fit 1986-up
Softail models. Features LED slice tail lamp.
VT No. Mounting Type
33-1135 Flat
33-0593 Curved
33-1918 Flat
33-0635 ⁵⁄₈” Axle Nut
33-0653 LED Array Only
33-0635
33-0635
33-0593
33-1918
33-1135
Side Mount Billet Chrome Tail Lamp Assemblies feature
mini rectangular lamp.
VT No
Type
Mounting Type
33-0383
Skull Softail
33-0384 Plain Softail
33-0722
Skull
¹⁄₂
” or ³⁄₈” Stud
33-0723
Plain
¹⁄₂
” or ³⁄₈” Stud
33-0640
Skull
⁵⁄₈
” Axle Nut
33-0641
Plain
⁵⁄₈
” Axle Nut
33-0641
33-0640
33-0721
33-0568
33-1136
Billet LED Slice Side Mount Tail Lamp Assembly.
VT No. Mounting Type
Finish
33-0568 Softail fits ³⁄₄” or 1” axle
Chrome
33-1525 Softail fits ³⁄₄” or 1” axle
Black
33-0639 As Above ⁵⁄₈” Axle Nut
Chrome
33-0721 ¹⁄₂” or ³⁄₈” Stud
Chrome
33-1136 Softail fits ³⁄₄” or 1” axle
Chrome
Warranty
LED Boards will be warranted only. No credit will be issued on any Lamps or
components with the 33 prefix. Lamps will either be exchanged or repaired and
returned to the dealer.
Side Mount Billet Tail Lamp Bracket fits left side of 1986-99
FXST or can be attached with clamps. Order clamps separate-
ly. Utilizes 3-bolt plate and lamp assembly. Builder must use
clamps or fabricate brackets to attach to frames. Lamps include
3 hole plate to mount to 31-0647.
VT No.
Item
Style
31-0647
Bracket
—
33-0353 Lamp
Diamond
33-0385 Lamp
Skull
33-0385
Installed
33-0353
31-0567
33-0385
33-1525
