1239
MULTI FIT/CHOPPER
Solo for XL’s
47-0133
47-0131
47-0134 shown
with 50-0246
luggage rack
VT No.
Model
Frame Cover
31-4044
1952-78
—
31-4045 1982-2003
42-0979
31-4063 2004-06 Included
31-0433
1979-81
—
31-4086 2010-up Included
Model 57 Solo Seat Kits include replica genuine leather solo
seat with complete mount kit. Replica seat is as offered on origi-
nal 1957 Sportster 50 years ago. 47-0782 includes frame cover.
VT No. Item
Cover
47-0781 1982-03 42-0979
47-0782 2004-06 Included
VT No. Item
31-0512 “T”
37-9114 Pivot Bolt
51-0539 Mount Tab Set
Solo Seat Mount
Hardware. This seat tee
and the weld on mount
tabs provide a substantial
mount system from K and
XL models solos. Order
pieces separately.
51-0539 Weld On
Mounts Shown
51-0539
K
31-4044
31-4045
31-0433
Installed
31-4045 Kit
Installed
Bates Solo VT No. 47-8655
Shown Mounted with
31-4063 Mount Kit
Solo Seat Mount Kits for Sportster
31-4063
Chrome Swingarm Rear
Spring Support Bar for
1952-78 only.
VT No. 31-0501
31-4086
Seat Mount Bracket Kits for 2000-up XL.
VT No.
Type
Fits
31-1542
Solid
2010-up
31-1543
Spring
2004-06, 2010-up
31-1542
31-1543
Leather Solo
Seat Kits for XL
models includes
seat, chrome
2” springs and
mount hard-
ware. 47-0134
includes frame
cover.
Smooth Bates
Kit
Item
Cover
47-0131 47-0813
—
1952-78
—
47-0132 47-0814
—
1979-81
—
47-0133 47-0810*
—
1982-2003
42-0979
47-0134 47-0811
31-4063 2004-06 Included
—
47-0812
—
2010-up
Included
47-0803 —
— 2010-up Included
31-4063
47-0810
*Note: Includes mount
kit.
Solo Hardware Mount
Kits include nose brack-
ets, springs and rear
brackets. To fit police
style solos purchase
cross bar 31-0473. 2”
spring. 31-4063 includes
black frame lower.
