1250
Note: Seat “Tee” Components are compatible with seat spring posts
as fitted to 1930-80 models of Big Twins and 45 models. Big Twins
1930-80 are machined to fit a seat post bushing and seat post.
Black Replica Tank Divider
replaces rubber filler strip when
a seat tee bar is used. Replaces
61122-39.
VT No. 28-0653
28-0653
28-0653
Installed
Seat Tee Black Bar will mount police
an buddy seats to 1936-84 74 and 80
and 1929-73 45” equipped with seat
posts. Fabricated from square solid
steel and accepts a ³⁄₈” bolt. Purchase
VT No. 31-0177 separately to mount
buddy seats.
VT No. 31-0511
Replica Seat Post and Tee Set includes fully assembled
post and replica forged steel seat Tee and related hardware.
Cadmium kits include heavy duty cad plated post assembly
with black tee.
Chrome
Black
Year
Model
Post
31-0614
31-0616
1941-64
Big Twin
31-0615
31-0617
1965-80
Big Twin
31-1241
31-0977
1937
Big Twin
31-1341
31-0622
1929-73
45
49-0978
1938-40
Big Twin
Cadmium Post
31-0618
1941-64
Big Twin
31-0619
1965-80
Big Twin
31-0511
Seat Tee Pivot Bolt and Bushing Kits.
VT No. Years
Use
8875-5 1937-64
Big Twin
Colony
1929-52
45”
8875-5T As Above
V-Twin
9676-5 As Above
Parkerized Colony
9676-5T As Above
Parkerized V-Twin
8876-5* 1965-80
Big Twin
Bushings Only
10-2500 1937-64
10-2501 1965-80
10-2501
Zinc Front Nose Bracket required to mount
all buddy seats to mount systems.
VT No. 31-0177
Seat Tee
45 Seat Mount U Clamp to be welded on 1929-
73 frames. Replaces 47066-26.
VT No. 49-2527
Solo Hardware Kit includes special 52098-34 bolt, (2) 52096-
34 washers, (6) 52108-81 spacers & nuts to mount 47-0110
seats to stock tee bar.
VT No. Finish
Item
8873-18 Cadmium Kit
Complete
31-0587 Cadmium Kit
Complete
9696-18 Parkerized Kit Complete
49-0188 Zinc Bolt
Each
31-0587
9696-18
31-0623
31-0630
31-0630
Installed
Replica Forged Steel Seat Tee features original construction
and shape for the authentic look. 1936-64 includes ⁵⁄₁₆” bolt
1965-80 includes ³⁄₈” bolt.
VT No. Fits
Finish
Model
49-1328 1936-E37 Black
EL
49-1376 L1937only Chrome
EL-UL
49-0270 L1937only Black
EL-UL
31-0623 1930-36 Black
45”
31-0630 1930-36
Chrome
45”
31-0624* 1938-40
Black
Big Twin and 45”
31-0569* 1941-64
Black
Big Twin and 45”
31-0570* 1941-64
Chrome
Big Twin and 45”
31-0415* 1965-80
Black
Big Twin
31-0513 1965-80
Chrome
Big Twin
31-0081 1936-64
Raw Strap
49-1381 1941-80
Seat T Cross Strap, Raw
49-1518 1936-72
45” Front Seat Bracket
49-1380 1941-57
Seat T Spacer Rivet Plate, Raw
*Note: Includes two stage front bushing.
31-0415
31-0569
31-0624
49-0978
31-1341
9676-5T
31-0570
49-1328
49-1376
49-0270
31-0977
