1252
VT No. 8623-2
VT No. 31-0177
VT No. 31-0198
VT No. 31-0407
VT No. 31-0408
Auxiliary Spring Assembly Kits Are Used With Seat Tee
Bars for All Buddy and Police Size Solos.
Chrome Frame Cover include hardware as
for Big Twin frames.
VT No. Year
Type
42-1375 1958-64 Swing Arm
31-9982 1958-80 Frame Cross Stud
Auxiliary Seat Spring
Auxiliary Spring Assembly includes parts pictured for 1936-
57 Big Twin rigid frame. Order the Spring Clip Kit and spring
hook separately.
VT No. OEM
Item
31-3999 52560-36 Complete Assembly,1936-57 Big Twin
31-4061 Chrome
Complete Assembly, 1936-57 Big Twin
13-9198 52575-33 Spring, Chrome, pair
13-9209 52575-33 Spring, Black, pair
31-3997 52581-36 Support Bracket
31-3996 52592-36 U Clamp, pair
49-1157 13330-36A Mount Stud Hex Type, Parkerized, pair
31-3995 52603-36 Mount Stud Round Type, pair
31-0408 52588-38 Yoke Hook Set
73341-36 1936-57
31-0198 52586-36 Yoke Hook, Chrome
31-0454 52586-36 As Above, Parkerized
31-3998 52567-36 Yoke
37-0862 7859
Nut, Four Piece
49-0449
Dome Cover Set
Auxiliary Spring Clip Kit
includes 2 of each part listed
52600-36, 52596-36, 52543-36,
and bolts and wing nuts for clip-
ping spring yoke to bottom of
buddy seats.
VT No. 31-3990
31-4061
42-1375
VT No.
OEM
Item
31-3973 52562-33
Complete Assembly
includes yoke bar, chrome springs and clamp set.
13-9198 52575-33
Chrome Springs
13-9209 52575-33
Black Springs
31-3972 52579-41
Frame Clamps, Four Piece
31-3958 52565-41
Spring Yoke Bar
Order Related Parts Separately
31-0407 52585-41
Spring Hook
31-3990 52600-36
Spring Clip Kit
49-0177 52652-29
Rear Peg Set, Parkerized
27-1454
Peg Yoke Set
31-3990
49-0177
13-9198
13-9209
45 Auxiliary Seat Spring Kit includes black finished parts
with chrome springs. Order spring clip kit and spring hook
separately.
Chrome Front Solo Seat Mount Kit.
Fits 1986-up FXST.
VT No. 31-0819
Buddy Seat Hardware
VT No. OEM
Item/Finish
8623-2
51918-29
Clevis pin with Spring
31-0177 52551-36 Front Bracket, Cadmium
31-0198 52586-36 Spring Hook, Chrome
31-0454 52586-36
As above, Parkerized
31-0408 52588-38
Spring Hook Set
52887-36
1936-57, Parkerized
31-0407 52585-41
1941-52, 45 Solo
31-0156
3 hole Under Fender Mount Strip
31-1283
Seat and Hook Only
Black Seat Post and T Kit fits 1936-52.
VT No. 31-0977
Seat T and Shock Piston Set.
VT No. Finish
31-0965 Chrome
31-1781 Black
54-0057 Bushing
31-0965
31-1781
