MULTI FIT/CHOPPER
Auxiliary Seat Spring Kit
Auxiliary Spring Bracket Assembly fits 1958-64 Big Twins,
order 31-3990 clip kit and hook separately.
VT No.
# OEM
Item
31-0427 Kit
Complete
31-0429 A 52567-58
Spring Yoke
13-9240 B 52575-58
Spring Set, Chrome, pair
31-0428 C 52581-58
Right Support Bracket
D 52582-58
Left Support Bracket
37-9110 E 52602-58
Stud Spring Mount
37-8792 F 52605-58
Support Stud Nut
37-9111 G 52606-58
Spring Support Spacer, pair
37-0862 H 7859
Nut, Black
37-0871 H 7859
Nut, Chrome
Footboard Extension Pads clamp on 1914-65 footboards.
VT No.
Finish
49-2556 Parkerized
49-2557 Chrome
Buddy Seat Foot
Rest Brackets mount
to existing footboard
brackets on 1936-64
Big Twins. Pair replac-
es 52674-41 and
52676-41.
VT No. #
Item
27-1628 A
Chrome Brackets
27-1629 A
Black Brackets
49-2556 B
Footboard Pad, Parkerized
49-2557 B
Footboard Pad, Chrome
8774-18 D & E Bolt Set, Cadmium
9722-18 D & E Bolt Set, Parkerized
27-1676 C
Peg Set with Rubbers, Zinc
27-1680 C
Peg Set with Rubbers, Chrome
28-2127
Rubbers only
Auxiliary Spring
Kit adapts to all
plunger mount-
ed buddy seats
for extra weight
Capacity. Includes
all parts pictured
to fit 1965-84 FLH
frames. Zinc plat-
ed with chrome
springs.
VT No.
#
OEM
Item
31-9978 All Complete
Kit
31-9967 A
52583-68
Bracket Left
52584-68
Bracket Right
31-9968 B
52566-65
Bar
31-9969 C
52586-68
Spring Bracket (2)
31-9970 D
52596-65
Yoke (2)
37-8800 E
52608-68
Shoulder Bolt (2)
F
52609-68
Cup Washer (2)
31-9982 G, H 52605-65
Stud with Spacer
52605-68
13-9174 I
52575-65
Spring, pair, chrome
37-8792 H
52605-58
Spacer Nut (2)
37-0510 J
5667
Square Head Bolt
31-9978
Footboard Hinge Bolt (Buddy Footrest
Bolt) Kit includes reproduction of special
shoulder bolts, pins and bushings used to
mount floor boards on 1941-64.
VT No.
Finish
8774-18 Cadmium
9722-18 Parkerized
27-1680
49-2556
31-0427
Rear Foot Rests include rubbers. Fit
1936-64 foot rest brackets.
VT No.
Finish
27-1676 Zinc
27-1680 Chrome
28-2127 Rubber Only
Complete Buddy
Footrest Kit.
VT No. Finish
